LED Driver 100W Constant Voltage 12V LED Switching Power Supply

Product Description

Led driver 100w constant voltage 12v led switching power supply
Features:

-12V20W Waterproof LED power supply, constant voltage.
-Epoxy encapsulated, IP67. Suitable for outdoor lighting application.
-Automated protection for over load and over temperature
-Aluminum housing, good for heat dissipation
-Cooling by free air convection.
-Application: LED display, LED sign, LED channel letter, LED underwater light, LED outdoor decorative lighting.
Specification:

AC Input	Voltage	90-264V AC	90-264V AC
	Frequency	47-63 Hz	47-63 Hz
	AC Current	0.82A max@220V	0.80A max@220V
	Efficiency	81%	85%
DC Output	Voltage	12±0.5V	24±0.5V
	Current	0-5A	0-2.5A
	Rated Power	60W	60W
Protection	Over Load	20% exceed in short time is allowed
	Short Circuit	Auto recovery
	Over Voltaqge	≤280V
	Over Temperature	≤85°C
Others	Store Temperature	- 40--85°C
	Wokring Temperature	- 20--55°C
	Dimension/Weight	138x70x40mm / 800g (Aluminium Housing)
	Packing/Carton Size	20PC/CTN 45*20.3*26 cm
	Input Cable	VDE H03VV-F 3G×0.75mm2 (200mm)
	Output Cable	VDE H03VV-F 2×0.75mm2 (200mm)
Certificate	CE	Compliant to EN 60950-1:2006;EN61000-6-3:2001; EN 55022:2006+A1:2007; EN61000-4-2/-3; EN61000-6-1:2001; EN55024:1998+A1:2000+A2:2003
	RoHs	Free from lead, Cadmium, Mercury, Hexavalent Chromium and/or PBB &PBDE

Company Profile :
MSS LED was established in 2011 and our Core team members engaged in LED industry since 2007, nearly 10years experience we foucs on led strip lights, led sign modules, related advertisement lighting products, and accessory led power supplies, dimmer, controllers etc.
Except standard strip lights and modules, we can offer the custom made product as exact demand, eg. Different length, one-to-one connector, indicated color temperature/color rendering/lumens/watts; or some clients told us where use lights, or what project/object they plan to install lights, then our expert team will offer suitable solution;

---
