Product Details
Product Description
Product Description
Commodity
| O1/sks3/1.2510/4Cr13/DF-3/9CrWMn/GS510 cold work die steel |
Grade
| H13 H11 1.2344 Vidars W301 SKD6 8402 8407 W302 SKD61 H21 |
Brand
| TISCO, BAOSTEEL, POSCO, JISCO, LISCO
|
Certification
| SGS, BV, etc
|
Diameter
| 6-200mm, or as per requirements
|
Length
| 3000mm-12000mm, or as per requirements
|
Surface
| Polished,bright,black,etc
|
Standard
| ASTM, AISI, SUS, JIS, EN, DIN, etc
|
Delivery time
| Two weeks after confirming the order
|
MOQ
| 3 tons
|
Quality control
| a)Mill Test Certificate is supplied with shipment.
b)Third party inspection is highly welcomed.
|
Application range
| Make chip stamping die, jewelry embossing die,Cold drawing die, wire die,Stamping die, thimble, guide sleeve, push rod and small and medium drills
|
The DAC55 steel is modified from the DAC (SKD61).
The advantages of DAC are retained, and better heat - resistant crack property is obtained. DAC55 steel has good toughness, ductility and cracking resistance. The chromium element which can improve the fatigue resistance and toughness of the die is added. Suitable for large, complex structure, precision, long life requirements of die casting die, high performance die casting die, extrusion die, etc.
DAC55 die steel die characteristics:
High toughness, high ductility, good resistance to cracking
Added chromium to improve the fatigue resistance and toughness of the die
Excellent heat crack resistance, high precision size
Good high temperature strength, good quenching
DAC55 die steel application:
Suitable for large die casting die, high performance die casting die, etc
Die casting die, extrusion die, precision die casting die
Stamping die, hammer forging die, upsetting forging tool, shearing die
Cold punching, trimming, hot shearing, tightening ring and wear-resisting parts
DAC55 die steel hardness:
Factory hardness: 229HB
Hardness: 46-52HRC
>>
