Product Description
Product Description
Factory Introduction
Certifications
Technical Specifications
ITEM
| CT-312
| CT-312
|
Input Power Voltage(V)
| AC 110V ; AC 220V
| AC 110V ; AC 220V
|
Input Power Frequency(Hz)
| 50/60
| 50/60
|
Rated Input Capacity(KVA)
| 3.5
| 4.5
|
Output Current Range(MMA）
| 10-110
| 10-140
|
Output Current Range(TIG）
| 11-120
| 10-160
|
Output Current Range(CUT）
| 10-30
| 10-40
|
No-load Voltage(V)
| 230
| 240
|
Rated Duty Cycle(%) 35%
| 60
| 60
|
Arc Start
| HF
| HF
|
Power Factor
| 0.93
| 0.93
|
Air Pressure(mpa)
| 0.2-0.4
| 0.2-0.4
|
Protection Grade
| IP22S
| IP22S
|
Dimensions（mm）
| 440*155*300
| 460*210*360
|
Weight（Kg）
| 8.6
| 12.7
|
Technical Specifications
ITEM
| UNIT
| CT-312
| CT-416
| CT-520
|
Input Power Voltage
| V
| AC380V±10%
| AC380V±10%
| AC380V±10%
|
Input Power Frequency
| Hz
| 50/60
| 50/60
| 50/60
|
Rated Input Capacity
| KVA
| 3.5
| 4.5
| 5.5
|
Output Current Range (MMA)
| A
| 10-110
| 10-140
| 10-160
|
Output Current Range (TIG)
| A
| 10-120
| 10-160
| 10-190
|
Output Current Range (CUT)
| A
| 10-30
| 10-40
| 10-50
|
No-load Voltage
| V
| 230
| 240
| 240
|
Rated Duty Cycle
| %
| 60
| 60
| 60
|
Arc Start
|
| HF
| HF
| HF
|
Power Factor
| cosΦ
| 0.93
| 0.93
| 0.93
|
Air Pressure
| mpa
| 0.2-0.4
| 0.2-0.4
| 0.2-0.4
|
Protection Grade
|
| IP21S
| IP21S
| IP21S
|
Dimensions
| MM
| 410*155*300
| 460*210*360
| 510*210*360
|
weight
| Kg
| 8.6
| 12.7
| 17.8
|
Packing & Delivery
More welders
FAQ
Q: What's your factory MOQ?A: MMA Welder MOQ200 ,TIG/MIG/PLASMA CUT MOQ50,.Sample available.
Q: Can i customize my own Logo/carton/machine's color?A: We are OEM factory ,LOGO and color design based on 300pcs, carton design based on 500pcs.
Q: I order goods for own use ,how to do it?A: We are factory no retail.if you want to place a trial order,depending on inventory .For a small amount of goods, the shipping fees is really expensive,to be borne by the buyer.
Q: How long your lead time?A: Generally,35-60Days.
1. Advanced inverter technology, energy-efficient and low noise.
2. Use compressed air as cutting gas source, cost-effective.
3. Air pressure and cutting current adjustable.
4. Easy operation, narrow cutting seams, smooth cutting performance and less deformation.
5. Circuit protection against over current, over voltage and over heat.
6. Suitable for cutting carbon steel, stainless steel, alloy steel, copper and aluminum, etc.
7 .Widely used in iron structure construction, manufacturing and automobile maintenance.
