High Viscosity Lobe Pump for Cream Gel

Product Description

movable rotor pump for viscosity liquid rotary lobe pump Specification

Model		Z-3	Z-6	Z-8	Z-12	Z-20	Z-30
Displacement L/100rpm		3	6	8	12	20	30
Speed range rpm		200~500	200~500	200~500	200~500	200~500	200~400
Corresponding flow L/H		300-800	650-1600	850-2100	1300-3200	2100-5400	3200-6400
Moroe power Kw		0.55	0.75	1.5	2.2	3	4
Orifice Size mm		Φ25×1.5	Φ25×1.5	Φ25×1.5	Φ32×1.5	Φ38×1.5	Φ50.8×1.5
Size	L	710	780	850	980	1000	1050
	H	290	390	400	450	450	480
	H1	150	170	170	185	190	220
	W	150	190	190	220	250	270
	W1	240	240	280	330	330	350
Tips		The specification listed here only for reference.

High Viscosity Liquid Lobe Pump
Rotary Pumps are exceptionally versatile. While they are often used on thin liquids such as solvents and fuel oil, they excel at efficiently pumping thick liquids such as asphalt, chocolate, and adhesives. The useful viscosity range of an internal gear pump is from 1cPs to over 1,000,000cP.
In addition to their wide viscosity range, the pump has a wide temperature range as well, handling liquids up to 750ºF / 400ºC.
High Viscosity Liquid Lobe Pump
For more details information of our rotary pump, please get in touch with us directly:
