Factory Low Price China Conventional Lathe Machine Ca6150

Product Description

China Machine Tool Metal Cutting Lathe Machine CA6150

Item		Unit	CA6150
1	Max. swing over bed	mm	500
2	Max. swing over carriage	mm	300
3	Max. length of work piece	mm	750
4	Width of bed	mm	400
5	Section of turning tool	mm	25x25
6	Spindle speed	rpm	16-1400 (24 steps)
7	Hole through spindle	mm	52
8	Spindle head form		ISO(GB)C6
9	Spindle taper		MT6
10	NO. of feed		64 kinds
11	Range of metric threads		(1-192mm)44 kinds
12	Range of inch threads		(1-24tpi)21 kinds
13	Range of module threads		0.25-48(module 39 kinds)
14	Range of diametral pitc threads		1-96DP(37 kinds)
15	Max. tailstock spindle travel	mm	150
16	Tailstock spindle diameter	mm	75
17	Taper of tailstock spindle center hole		MT5
18	Main motor power	kw	7.5
19	Machine size	mm	2440x1140x1750
20	Weight	kg	2060

Machine Detailed Photos
Standard Configuration:
(1) 3-jaw chuck.
(2) Four station electric tool post.
(3) Manual tailstock.
(4) Cooling system.
(5) Lighten system.
(6) Automatic lubrication system.
Optional Configuration:
(1) φ320mm jaw chuck and chuck holder.
(2) Faceplate.
(3) The events leading.
(4) The center frame.
(5) With the cutting tools.
After-sale Services:
Warranty is one year.
We would offer the parts (quality problem) free of charge during this period, freight collect.
Company Information:
Taian Yuzhuo Machinery Co., Ltd. ( or "YZ CNC" for short) is a professional manufacturing enterprise
engaged in the research, development, production, sale and service of CNC machines.
Dedicated to strict quality control and thoughtful customer service, our experienced staff members are
always available to discuss your requirements and ensure full customer satisfaction.
Our main products are as below:
* Wheel Repair CNC Lathe Machine
* Vertical CNC Lathe Machine
* Horizontal CNC Lathe Machine
* Slant Bed CNC Lathe Machine
* Universal Lathe Machine
* Pipe Threading CNC Lathe Machine
* CNC Milling Machine
* CNC Vertical Machining center
All the above products have passed CE, SGS certificates.
Our Strength
* Over 18 years manufacturing experience in CNC lathe machine.
* Quality is the life of our company, and we offer you the best high value added machines.
* Export CNC machine tools to all over the world, especially to UK, US, Europe and Middle East countries.
* Customer service is the power that drives our company forward.
Contact Us
If any interest about our cnc milling machine or cnc vertical machining center, please just contact us freely.
And we warmly welcome you to visit our factory at any time, thank you.

---
