| US$1.50-2.00 | 10 Pieces (MOQ) |
| Design Specifications | Typical |
| Working Frequency | 1575.42MHz |
| Gain | ≤3.0dBi |
| Antenna efficiency | 45% |
| VSWR | ≤2.0 |
| Ploriaztion | RHCP |
| Axial Ratio | ≤3.0 |
| Radiation pattern | Omni |
| Impedance | 50Ω |
| Power handling | 33dbm |
| Interface | SMA Male/ RG174-3M |
| Overal dimensions | 48.5x37x17 |
| Weight | 60.5g |
| Operatin Temp | -40ºC~80ºC |
| Storing Temp | -15ºC~30ºC |
| NO | Item | (Specifications) |
| 1 | Frequency range | 1575.42±3MHz |
| 2 | Amplifier gain | 28±3 dBi |
| 3 | V.S.W.R | ≤2.0 |
| 4 | Noise Figure | <2.0 |
| 5 | DC Voltage | 3~5V |
| 6 | DC Current | ≤20mA |
