Xt-X-5A Surgical Microscope Is Mainly Used for Microvascular Anastomosis and Animal Experiments in Spinal Surgery, Hand Surgery, Urology, Ophthalmology

Product Description

Purpose
XT-X-5A surgical microscope is mainly used for microvascular anastomosis and animal experiments in spinal surgery, hand surgery, urology, ophthalmology and other surgical microsurgery.
Product Features
Japan OLYMPUS new original primary mirror, 65mm width field of view, 4X-20X stepless continuous doubling.
Coaxial lighting, German OSRAM halogen lamp, imported material light guide fiber, high brightness and strong penetration.
With the optical path assistant mirror 4X-20X, can focus independently.
X-Y plane mover, imported low-noise servo motor, stable and reliable.
Imported zoom device, low noise, accurate positioning, good stability.
Stepless variable times using imported motor, low noise, good stability.
New appearance beautification design, humanized operation, convenient installation and debugging.
Technical parameters
1.microscope section
primary mirror

Eyepiece	12.5X Alf type wide-angle eyepiece
Observation slope	45°
Interpupillary distance	50mm-76mm, continuously adjustable
diopter adjustment	7D (binocular)
X-Y speed regulation	2.5 mm/s foot control
magnification	4X-20X electric stepless continuous magnification
field of view	8mm-65mm
working distance	≥ 180mm

assistant mirro
Stereo same light path, 4X-20X manual stepless continuous zoom
The assistant mirror is rotatable and forms a 90°-180° position with the main mirror.
2. lighting system

form	wide-diameter light guide fiber, cold light source coaxial lighting
light source	double lamp 15V/150W, German OSRAM halogen lamp
control mode	four-level dimming
illuminance	≥ 50000LX
power supply voltage and frequency	220V 10% 50Hz

3. frame part

Cross arm length	1230mm
up and down adjustment range	250mm
Fine adjustment range	40mm
Foot control switch	X-Y plane mover, electronically controlled zoom, electronically controlled fine adjustment

---
