Product Details
Product Description
Product Description
Semi automatic stitch machine
♦ Mitsubishi dual servo drive, precision, mechanical transmission part reduction. can effectively reduce the mechanical failur rate.
♦ weilun touch screen operation, parameters (nail distance, nail number, nail type, backboard) easy to change.
♦ the whole control system adopts Japanese omron PLC control system
♦ rear electric baffle, driven by stepping motor, accurate size, more convenient and fast size conversion.
♦ the full contactor in the control box adopts the brand of Siemens.
♦ relays are all made by schneider.
Semi automatic sewing stitching machine
♦ photoelectric and proximity switches adopt Japanese omron brand.
♦ bottom die, the blade is made of Japanese tungsten steel (wear-resisting).
♦ the whole set of nail head are all made of special steel, computer gong precision processing.
♦ single stitching/, double stitching//, reinforcing stitching(// // // /double stitching at both ends and single stitching at the middle part)can be finished in one time, which can meet different requirements of different customers.
♦ it only takes one minute to change the carton size and adjust the carton stitching distance, which greatly saves time and is convenient to operate.
♦ the front feeding part is automatically counted, and the feeding table is equipped with photoelectric induction device, which automatically rises when feeding.
♦ the back section is equipped with automatic counting function, and the finished pieces can be stacked and sent to the end of the transmission machine according to the set quantity(2-99), which is convenient for packing and binding
♦ electric adjustment of the clearance of the paper press rubber wheel.
♦ machine order type adjustment, can store 100 orders.
♦ protection function of isolating transformer for the whole machine;
♦ automatic wire feeding svstem, 20KG flat wire, save time.
♦ front and rear two-way baffle configuration,can order lideless carton and small cardboard box. color box.
Model
| BDJ-2000B
| Bdj-2500b
|
MAX (A+B) *2(mm)
| 3740 (1100+770)
| 4740
|
MIN (A+B) *2(mm)
| 700
| 560
|
MAX (C+D+C) (mm)
| 2500
| 2500
|
MIN (C+D+C) (mm)
| 400
| 450
|
MIN rock cover C (mm)
| 20
| 75
|
MAX rock cover C (mm)
| 310 500 (optional)
| 500
|
MAX width B (mm)
| 770
| 920
|
MIN width B (mm)
| 150
| 150
|
MAX length A (mm)
| 1100
| 1450
|
MIN length A (mm)
| 200
| 200
|
MAX height D (mm)
| 2000
| 2000
|
MIN height D (mm)
| 150
| 150
|
MAX width of the tongue E (mm)
| 40
| 40
|
MAX height of feeder (mm)
| 900
| 900
|
Overall dimensions (mm)
| 2850*1700*1800
| 3300*1700*1800
|
Weight (T)
| 2
| 2.3
|
Speed (Nail / min)
| 600
| 600
|
Number of Stitching
| 2-99
| 2-99
|
WELLDOING TRADING Co. Ltd. is a manufacturer + sales and after-sales company, which is mainly engaged in large-scale semi-automatic chain-bar water-based printing machine,automatic flexo printer slotter die cutter stacker machine , high-speed high-definition paper box printing and slotting die-cutting machine, 2 layers corrugated production line, box-sticking machine, Tying Machine ,Automatic Partition Assembler Machine,automatic carton box folder gluer machine, semi-automatic carton floder gluer machine paper tube making machine, flexo ink printing wastewater treatment machine 3,5,7ply corrguated cardboard production line and so on.
Our Services
1. OEM service are available.
2. Trade Manager online, also contact by Email.
3. To solve problems by pictures/videos.
4. Engineers are available service abroad.
FAQ
1. Are you a factory or trading company?
We are both a factory and a trading company in this field .
2. What is the terms of payment you accept?
We usually accept the T/T payment, we need 30% of total amount as deposit,
pay the 70% balance before delivery, but we can also accept the L/C.
3. How does your factory do regarding quality control?
Quality is priority. We always regard great importance to quality controlling from the very small thing(even a small screw we will choose the best quality) from the beginning.
If you are also interested in this machine,please don’t hesitate to contact us:
Overseas manager: Tom Wang
Email:cartonmachine.tomwang@aliyun.com
Phone/Wechat/Whatsapp:+86 13303078975
>>
