High Precision and Efficiency and Cheap Price Ty-300 Instrument CNC Lathe

Product Description

Product Description
The TY-300 digital control lathe has several significant advantages compared to traditional CNC lathes:
Precision Machining, Flange Specialized: TY-300 CNC lathe, designed specifically for precision instrument flange machining, ensuring high accuracy and stability.
Automated Efficiency Enhancement: Equipped with an automatic feeding system, enabling efficient continuous processing and injecting new momentum into production efficiency.
Versatile Applications: Suitable for various precision instrument flange machining tasks, including threading, hole drilling, and more, meeting diverse production needs.
Overall, the TY-300 digital control lathe offers clear advantages over traditional CNC lathes in terms of precision, efficiency, automation, adaptability, and data-driven management. It is a key equipment widely applied in modern manufacturing industries.
Product Parameters

ITEM	TY-300
System configuration	Open 821 / optional
Maximum swing diameter on the bed	φ350mm
Maximum swing diameter on the tray	φ140mm
X-axis maximum stroke	680mm
Z-axis maximum stroke	400mm
Spindle	Mechanical spindle / optional
Spindle rotation speed	50-3000rpm
Spindle end specification	A2-5
Spindle through-hole diameter	Φ48mm
Servo main motor power	4kw
X-axis servo motor	4nm
Z-axis servo motor	4nm
Clamping way	Pneumatic / hydraulic clamping
Cylinder specifications	Hydraulic hollow536/549
Knife frame form	Row knife/ optional
The knife number	4
Blade Square Size	20*20mm
The Z-axis of the guide rail form	Linear guide (30FZS)
Rail form X-axis	Linear guide (30FZS)
Bed form	Flat conjoined
X-axis fast movement	20mm
Z-axis fast movement	20mm
Weight	1100kg
Machine size	1650*1300*1600mm

---
