Stainless Steel Flat wedge Screen Panel
Stainless steel Flat wedge screen panel is made of SS "V"shaped and SS "V"shaped or SS "V"shaped
and SS Support "V"shaped rod ,and SS "V"shaped and SS "Square "shaped rod or Convex shape wire
with an unique weldeding process, offering great strenght .precision ,long service life . The Screen have
a perfectly flat and smooth surface with rectangular openings , also named flat wedge wire screen ,flat wedge wire screen panel or wegde wire .
The Support Rode : Square rode , "V" shape wire .Convex shape wire.
WEDGE PROFILE WIRE
|
|
B (mm)
| 1.50
| 1.50
| 2.30
| 2.30
| 1.80
| 3.00
| 3.70
| 3.30
|
H (mm)
| 2.20
| 2.50
| 2.70
| 3.60
| 4.30
| 4.70
| 5.60
| 6.30
|
α (°)
| 6° ,10° , 12°
|
GAP SLOT WIDTH(mm)
| 0.3mm-10mm
|
LONG WEDGE
SUPPORT WIRE
|
| Convex shape wire
|
|
B(mm)
| 1MM-3MM
| B (mm)
| 3mm-5 mm
|
H(mm)
| 4MM-6MM
| H (mm)
| 3mm-5mm
|
SUPPORT WEDGE WIRE
|
|
WIDTH(mm)
| 2.30
| 2.30
| 3.00
| 3.70
| 3.30
|
HEIGHT(mm)
| 2.70
| 3.60
| 4.70
| 5.60
| 6.30
|
Advantages:
A continuous slot opening which significantly increases the available open area, thus
providing a greater access to the water bearing zone.
A ’V’ shaped profile wire which avoids clogging and ensures uninterrupted flow.
A uniform and efficient well development due to the continuous slot opening
Uses:
Applications for wedge wire screen panels include cross flow sieves, vibrating screen decking,
mineral processing, surface water intake screens, fish diversion screen panels, hatchery screens,
Architectural Decorative food processing, and flooring for malt kiln, germination, and grain drying.
Wedge wire screen panels can be constructed using "V "support rods Convex shape wire and
Square support rods. Wedge wire screen panels can be designed to optimize the open area
strength and wear life for each application.
>>
