| TECHNICAL SPECIFICATIONS |
| Effective width | 190,220,230,250,260,280,340,360,400cm |
| Effective width reduction | 190cm: at least 70cm |
| 220 and 250cm:at least 90cm |
| 280,340,360and400cm:at least 96cm |
| Weft color selection | Up to 8 colors |
| Double or multiple weft insertion |
| Weft feeder | Adjacent yarn loops |
| Separating yarn loops |
| Automatic switch function of weft feeder |
| Positive weft tensor | Programmable weft tensor |
| Balloon limitor |
| Weft detection | Electronic weft scissors,each Channel can set the cutting time separately |
| Yarn change detector |
| Fixed and oscillating main nozzle |
| Auxiliary nozzle |
| Lenado's knot removal decive |
| Beam | 800,914,1000,1100mm |
| Back-beater | Universal type with built-in warp tension sensor |
| | Stable mechanism |
| Stop device | 6 electonic drop bars |
| | 25mm pitch or 8 drop bars |
| | 16mm pitch detection strip by strip |
| Take-up device | Roll diameter |
| | Direct take-up by pressing rollers |
| Main motor | The main motor directly drives the loom |
| | Intelligent frequency conversion control vehicle speed |
| Reed movement | Conjugate cam,with cam follower |
| Shedding | Positive dobby shedding for up to 16 shafts heald frame |
| Positive cam shedding for up to 8 to 10 heald frames |
| Cam mechanism with automatic levelling function |
| Heald frames for 330mm(13 o'clock) heald wire |
