| US$199.00 | 149 Pieces (MOQ) |
| 1 | HD small pixel LED display | P1.5625 / P1.667/ P1.923/ P2 |
| 2 | Hot rental LED display | P3 /P3.91 /P4 /P4.81 /P5.95 |
| 3 | Outdoor fixed LED display | P4/P5 /P6 /P8 /P10 /P16 /P20 |
| 4 | LED Control System | Nova Star / LINSN /Colorlight /Listen |
| 5 | LED | Nation Star /Kinglight |
| 6 | IC | 16380 /6373 /2163 |
| 7 | Power supply | Meanwell / G-energy |
| 8 | Cabinet kind | Iron /Aluminum /Die-casting /Fiber Aluminum |
| 1 | Pixel Pitch | 2.604mm / 2.976mm / 3.91mm / 4.81 mm |
| 2 | Cabinet Size | 500*500mm / 500*1000 mm |
| 3 | Pixel density | 65,536 dots/m2 |
| 4 | Color temperature | 6000K--8000K |
| 5 | Viewing angle | H: 140; V: 140 |
| 6 | Dead LED lamp rate | ≤0.1‰ |
| 7 | Non-Flatness | <0.2mm |
| 8 | Module interval | <0.2mm |
| 9 | Packaging Gross Weight(KG) | 8-12 kg (Estimated data) |
| 10 | Packaging dimension | 70*70*75c m (6cabinet in one case) |
| 11 | Max power/m2 | 1000 W/m2 |
| 12 | Brightness adjusted | 256 grade by auto-optic/color &8 grade by hand |
| 13 | Input signal | RF, S-video, RGB, RGBHV, YUV, YC&Composition, etc |
| 14 | Life-span | ≥1 00, 000 hours |
| 15 | MTBF | 5, 000 hours |
| 16 | Frame frequency | 25 - 60 Hz / s |
| 17 | Refresh rate | ≥2, 000 Hz / s |
| 18 | Single Input(with video processor) | HDMI, DVI, VGA, RF, S-Video, RGB, RGBHV, YUV, YC&Composition, etc. |
| 19 | Control Distance | 120 m (no repeating); Optical fiber Transmission: 0.5km- 10km |
| 20 | Systems Operating Platform | Windows XP, Win 7, Win8, Win8.1, Win10 |
