Waste Liquid Processor Developer Curing Treatment

Product Description

Waste Liquid Processor Developer Curing Treatment
Model: ECOO-TD9900-II-FX


Functions
Special treatment of developing waste liquid, automatic collection, extraction and online curing treatment.

Specifications

Intelligent Waste Liquor Curing Treatment System
Model	ECOO-TD9900-II-FX
Machine Size	1450*1080*1850mm
Power Supply	380V 50HZ
Total Power	4.5KW
Weight	260kg
Processing Capacity	5L/hour

Intelligent Waste Liquor Curing Treatment System
Model ECOO-TD9900-II-FX
Machine Size 1450*1080*1850mm
Power Supply 380V 50HZ
Total Power 4.5KW
Weight 260kg
Processing Capacity 5L/hour

Introduction
1] Automatic collection and centralized treatment of developing waste liquid.
2] All control systems are controlled by PLC and operated by touch screen. Fully automatic online operation, automatic collection and treatment of developing waste liquid.
3] Electric heating is adopted for concentration treatment.
4] The concentrated solidified products are discharged and solidified by automatic scraper.
5] After treatment, the solid waste can be automatically discharged into the fixed tank for easy cleaning.
6] No additional chemicals need to be added during the treatment.
7] The treatment residue is solid, and the remaining solidified product is about 10% of the original waste liquid.
8] The treatment rate is related to the composition of the developer, and the matching developer circulation filtration system can improve the treatment rate.

Usage Cost
Only electricity is used, with an average power consumption of 4 kwh/hour and no additional chemical agents use fee.
System Efficiency
1. Cost Effectiveness: solidification treatment of developing waste liquid, reducing the cost of hazardous waste transportation and treatment;
2. Environmental Protection Effect: reduce 90% of the discharge of developing waste liquid, and the distilled water quality reaches the national industrial wastewater discharge standard above grade 2 (implementation basis: GB8978-2002).
Producing and Packaging
From producing to delivery, we make every details very carefully to guarantee the good product quality and service to customers.
Certifications

FAQ

Q1: What are your main products ?
A: Our main products are the Prepress 4up and 8up Online/Offline Thermal CTP, CTCP, VLF CTP, Flexo CTP, Processor, Offset Plates, Offset Inks, Offset Printing Blankets, Postpress Packing Equipment and so on.
You can get the equipment and consumables all in one and no worry about the after-sales service from our company.
Q2: Where is your factory ?
A: Our CTP Processor machine factory is in Shanghai, you are warmly welcome to visit our factory!
Q3: What is your warranty for the CTPs ?
A: Three years' Laser Head and main spare parts for the CTPs, one year for the Processor. If the customer use EcooGraphix CTP plate with the CTP machine, we will provide the Lifetime Warranty.
Q4: Can you also supply the Workflow and RIP ?
A: Yes, we can provide the Workflow Brainnew and RIP Compose V12.
Q5: What about the installation and after-sales technician support ?
A: Our engineer can go to help the installation and provide the necessary training. The buyer should take the round air plane tickets, service charge and the local accommodation cost. Any problems or questions, we will be at your disposal 7x24 hours. Among our large amount of CTP installations worldwide, there are also many end users(printers) who have purchased the CTP products from EcooGraphix China directly and EcooGraphix technical service team support these installations remotely with regular onsite visits.
These end users printers all run the CTP systems with full satisfaction due to our robust quality, seamless remote service, thorough training and maintanence. If you are a printer who is considering purchasing directly from EcooGraphix China, there is no hassle on installations, training and after sales service. We guarantee your satisfaction.

---
