Inflatable Seated Concentric Butterfly Valve for Industrial Use with Inchangeable Seat

Product Description

Product Description
Series A31INF inflatable seated butterfly valves use air pressure to expand the seat against the disc, providing even pressure distribution for a bubble-tight seal in every close. Because the seat has no contact with the disc during valve opening and closing, there is minimum disc to seat friction.
In actual comparison tests and documented field applications, an A31INF butterfly valve lives more than one million cycles. For dry solids, gases, slurry and high abrasion applications, the A31 inflatable seated butterfly valve is unsurpassed.

Connection	Wafer
Nominal diameter	DN25-DN600
Max. working pressure	Up to 10Bar
Standard working pressure	Full vacuum to 8bar (According to air supply)
Flange accommodation	EN1092 PN10/16,ASME B16.5 Class150
Face to face	EN558 Series 20, API 609 Table 1
Top flange	ISO 5211
Tightness check	ISO 5208 Category 3, API 598 Table 5
Temperature range	-40°C to +200°C (Depending on pressure, medium and material)
Operation	Pneumatic actuator (DA, SA)
Torque	Varies with medium and application

Design Features & Working Principle of A31INF Inflatable Butterfly Valve
Product Parameters

Size		A	B	C	D	Di	Do	E	F	d	G	H	L	Weight (kg)
DN	Inch
25/32	1"/1 1/4"	110	51	13.5	75	34	61	9	50	8	70	19	30	1.5
40	1 1/2"	130	54	13.5	85	42	71	9	50	8	70	28	33	2
50	2"	135	72	19	94	52	86	11	70	10	90	32	43	3
65	2 1/2"	150	83	19	115	67	104	11	70	10	90	50	46	4
80	3"	161	92	19	135	81	122	11	70	10	90	69	46	5
100	4"	177	105	19	151	101	140	11	70	10	90	88	52	6
125	5"	195	120	19	185	127	141	14	70	10	90	115	56	8
150	6"	208	133	19	204	151	195	14	70	10	90	141	56	9
200	8"	239	170	25	265	202	248	17	70	10	90	194	60	13
250	10"	281	200	32	320	254	301	22	102/125	12/24	150	240	68	23
300	12"	316	236	32	375	300	354	22	102/125	12/24	150	290	78	31
350	14"	332	254	40	425	339	401	22	125	14	150	330	80	43
400	16"	367	301	40	475	388	451	27	125	14	150	377	102	58
450	18"	397	341	65	535	440	515	36	140	18	175	425	114	95
500	20"	437	382	65	590	490	573	36	140	18	175	475	127	125
600	24"	522	464	80	695	590	660	46	165	22	210	570	154	180

Company Profile
ABC Valve focuses on Automatic Butterfly valve Control. The manufacturing system and products are certified by ISO9001, BV Marine, CE, ATEX and TS. The cooperative team is knowledgeable in fluid control technology and make sure that ABC valves suppling to worldwide customers with high quality and competitive price.
With unique patent designs, special attention on user' s feedback, ABC valves are widely applied in lithium battery industry, food industry, pharmaceutical, textile dyeing, heating and cooling, municipal, shipbuilding, electronics, nuclear power, petrochemical, paper-making, environmental protection etc.
Mission of ABC Valve-- Make fluid control easier.
ABC Main Products
ABC Team with Clinets
Certifications
Packaging & Shipping
FAQ
1) Q: Are you a manufacturer or trading company?
A: ABC Valve is a professional valve manufacturer with experienced R&D team.
2) Q: Do you have any agent or representative abroad?
A: Yes, we have agents in some countries, they can offer local service for you.
3) Q: What kinds of valve can you supply?
A: We can supply butterfly valve, ball valve, check valve and so on.
4) Q: Do you have any certificate for the valves?
A: Yes, we have CE, BV, ATEX, TS and so on.
5) Q: What's the delivery time?
A: If all the parts of the valve are ready in stock, the valves can be delivered within 7~10 days. 6) Q: What are the countries or regions you supply valves?
A: ABC valves have been supplied to USA, Europe, Australia, Singapore, South Africa and so on.

---
