High Quality Aluminum Electrolytic Capacitor Running Aluminum Shell Film Capacitor for Air Conditioning

Product Description

High Quality Aluminum Electrolytic Capacitor Running Aluminum Shell Film Capacitor for Air Conditioning Product Description Product features:
Plastic and insulation shell, epoxy resin sealed, metal case,vegetable oil impregnation;
Product with small volume, light weight, high insulation resistance, high withstand voltage, low dissipation factor, good self-healing; stable performance;
Product application:
Applicable to water pump, washing machine, smoke lampblack machine or other single-phase power supply system asynchronous motor and three-phase asynchronous motor use single phase power supply.
We focus on providing one-stop core value refrigeration products and excellent service, among including CBB61, CBB60 and CBB65 film capacitors, refrigeration compressors, YZF series fan motors, DD/DJ/DL air cooler, and so on. Product Parameters

µF	110-300VAC		250-400VAC		370-450VAC
	D	H	D	H	D	H
2	30	60	30	60	30	60
5	30	60	30	60	30	60
10	30	60	30	60	34	60
15	30	60	34	60	34	70
20	34	60	36	70	40	70
25	36	70	40	70	45	70
30	40	70	45	70	45	80
35	40	70	45	70	45	90
40	45	70	45	80	45	100
45	45	70	50	90	50	100
50	45	70	50	90	50	100
60	45	90	50	90	50	110
70	50	90	50	100	50	125
80	50	90	50	100	50	125
90	50	100	55	100	55	125
100	50	125	55	125	60	125

Tech. parameter	Reference value
Voltage range	110Vac~450Vac,50/60Hz
Capacitance range	2 µF~100 µF
Capacitance tolerance	±5% (J), ±10% (K)
Operating Temp. range	-40ºC ~ 85ºC
Withstand voltage	T-T	2Un/60s
	T-C	2Un+1000Vac/60s(≥ 2200V)
Dissipation factor	≤0.004, 1000Hz
Altitude	≤2000m
Reference standard	GB/T3667.1, IEC/EN60252.1 UI810

Production Process
Certifications Company Profile Packaging & Shipping
FAQ Q1. Why choose Polarmint?·Variety Refrigeration Products Option for RHVAC;
·Technical support--professional technical team with more than ten years of experience, providing design and construction solutions;
·Quality gruarantee--we have complete inspection and test facilities to guarantee the high quality of products;
·Fast Delivery with High Quality;
·Professional Service Team of 24 hours on Line.Q2. How can I get the price?A: We usually quote within 24 hours after we get your inquiry, except weekend and holidays. If you are very urgent, pls e-mail us or contact us in other ways so that we can offer you a quote.Q3. How can we guarantee quality?A: Always a pre-production sample before mass production;
Always final Inspection before shipment.Q4. Can I buy samples before placing orders?A: Sure, feel free to contact us for samples.Q5. What is your lead time?A: It depends on the order quantity and the season you place the order. After confirm your order, the production usually will be 15-30 days. Q6. What shipping way?A: Depend on your requirement. For urgent order with light weight, you can choose air shipping.

---
