Graphene Homogenizer High Pressure Homogenizer Automatic Homogenizer

Product Description

1--About Us :
Shanghai Jinzhu Machinery Equipment Co., Ltd.is a company integrating R&D and manufacturing, production and sales, equipment engineering installation, and automation supporting services.
It specializes in the productions of Homogenizer , Plate Heat Exchanger & Pasteurizer , Tubular Heat Exchanger & UHT Sterilizer, aseptic tanks, Stainless steel Tanks & CIP cleaning automatic system. All the products and automation system equipment are widely used in dairy, pharmaceuticals, beer, beverages, food, biological products, fine chemicals and other fields.
Shanghai Jinzhu Company has always been adhering to the corporate tenet of "Quality, Health, and Thanksgiving", adopting internationally advanced production technology and rich on-site management experience to undertake more than 100 large-scale dairy products, functional foods, fruit juice beverages, fine chemicals and pharmaceutical projects at home and abroad.
This has won unanimous praise from customers. The company has a team of technical experts with many years of experience in equipment manufacturing, engineering installation, electrical automation, etc., and always adopts advanced overall processing solutions for dairy beverages, pharmaceuticals, beer, food, biological products, fine chemicals, etc. The enterprise provides intelligent control production equipment.

Entrepreneurial spirit: quality, health, gratitude!
Corporate vision: Let China's dairy beverage processing technology connect with the world!
2--Production Introducton
a-Lubricating system
Lubricating system which is both squirting and splash uses soft plastic pipes that can bear high pressure and oil. The oil can keep stable temperature at the same producing condition, so it brings excellent lubricate effect. The recycle cooling system reduces driving box's temperature and lubrication waste.
b-Driving box
The eccentric shaft is made of special alloy steel which is wear-resisting and has long using life. The half construction is easy to maintain and be knocked-down. Driving and eccentric shafts are driven by v-model gears which have following advantage: low noise and good stability.
c-Wear parts
Homogenizing valve, one-way valve and piston are made of special alloy steel, with high impact-resisting and corrosion-resisting. This material is applicable to any CIP's corrosion-resisting. In special condition homogenizing and one-way valves can be made of W alloy steel which has same function. All kinds of sealing material have following advantage: wear-resisting, non-toxic, pressure-resisting and long life.
It is easy and convenient to change wearing parts, especially it is no need to take off pump during changing pistons and sealing rings.
d-Pump construction
The square high pressure covers on the pump have high intensity and excellent sealing function. The tighten nuts with lids have nice out looking. The material gate is according to food sanitation and pharmacy standards. Out-in parts take adjustable tie-in which is easy and convenient to be taken off and fixed.
e- Homogenizer Type
CONLON homogenizes are all horizontal construction which advantage is good stability and easy to operate, maintain and repair.
f-Saving energy
Jinzhu homogenizers is base on low energy waste and high efficiency designing, which has clear effect at the same producing condition.
3--Our Services Quality - -A constant Journey
JZ's goal is to continue to be a leading provider of reliable, high quality homogenizers and spares to customers in order to help them to maximize their revenue, competitiveness and profitability.
This implies that all our products and services must be of extremely high quality and therefore we strive to achieve:
· Reliability
· High technical standards
· Value for our customers
Quality--Policy

JZ wishes to fulfill these goals by focusing on quality to achieve the best possible results:
· To deliver high quality products
· To supply fully operational applications
· To deliver according to specification and identified requirements
· To provide high quality professional services
4--After-Sales Service
a-Pre-sale service:
1.1 Our company provide free product technical solution, and give related technical lectures, help customers to meet the need of actual product selection and provide analysis on running economy.

1.2 our company take charge to provide related technology consulting for free, and according to the actual product is free to provide equipment design.

b- Sale service :
2.1 Our company provide installation instructions for the product and free training for the customer to product production technology, can arrange technical personnel door-to-door free training according to the needs of customers.
2.2 our company has excellent after-sales service, strict training to ensure that the user needs.
2.3 During installation, our company will provide technology consulting and equipment installation debugging field training, to ensure the normal use of the customer.
2.4Service hotline: + 86 (21) 33658304 , customers in the operation. Maintenance. The maintenance problems encountered in the process of the hotline service for you at any time.

c- After-sales service :
3.1Our company strictly abide by the after-sales service commitment, boot debugging within 6 months after the quality problem of the non-artificial factors caused by my company responsible for free maintenance (except for normal consumable spare parts)
3.2 Our company promises to provide life-long maintenance for equipment.
3.3 Spare parts, spare parts supply for life .
5-Main Products Photos
6--Main Technical Parameters
1 What's the production ?
2 What's the production capacity ?
3 What's the homogenizer rated pressure ? wroking pressure ? working Voltatge ?
4 Is there frequency converter with homogenizer ?

Model	Capacity(L)	Max Pressure (MPa)	Working Pressure (MPa)	Power (KW)	Weight (kg)	Size(cm)	Frequency converter
JZH1000-25	1000	25	0-20	7.5/11	700	88*73*88	Yes / No
JZH1000-30	1000	30	0-24	11	830	140*90*100	Yes / No
JZH1000-45	1000	45	0-36	15	830	140*90*100	Yes / No
JZH1500-30	1500	30	0-24	15	830	140*90*100	Yes / No
JZH1500-60	1500	60	0-48	30	1200	145*95*110	Yes / No
JZH2000-25	2000	25	0-20	15	1200	145*95*110	Yes / No
JZH2000-30	2000	30	0-24	18.5	1200	145*95*110	Yes / No
JZH2000-45	2000	45	0-36	30	1200	145*95*110	Yes / No
JZH2500-40	2500	40	0-32	30	1800	155*110*115	Yes / No
JZH3000-25	3000	25	0-20	22	1800	155*110*115	Yes / No
JZH3000-30	3000	30	0-24	30	1800	155*110*115	Yes / No
JZH3000-40	3000	40	0-32	37	1800	155*110*115	Yes / No
JZH3500-40	3500	40	0-32	45	2200	170*115*127	Yes / No
JZH3500-50	3500	50	0-40	55	2200	170*115*127	Yes / No
JZH4000-25	4000	25	0-20	30	1800	155*110*115	Yes / No
JZH4000-30	4000	30	0-24	37	1800	155*110*115	Yes / No
JZH4000-40	4000	40	0-32	45/55	2200	170*115*127	Yes / No
JZH5000-25	5000	25	0-20	37	1800	155*110*115	Yes / No
JZH5000-30	5000	30	0-24	45	2200	170*115*127	Yes / No
JZH5000-40	5000	40	0-32	55	2200	170*115*127	Yes / No
JZH6000-25	6000	25	0-20	45	2200	170*115*127	Yes / No
JZH6000-30	6000	30	0-24	55	2200	170*115*127	Yes / No
JZH6000-40	6000	40	0-32	75	3000	200*125*128	Yes / No
JZH7000-25	7000	25	0-20	55	2800	200*120*130	Yes / No
JZH7000-35	7000	35	0-28	75	3500	200*160*145	Yes / No
JZH7000-45	7000	45	0-36	90	3500	200*160*145	Yes / No
JZH8000-25	8000	25	0-20	55	2800	200*120*130	Yes / No
JZH8000-30	8000	30	0-24	75	3500	200*160*145	Yes / No
JZH8000-40	8000	40	0-32	90/110	3500	200*160*145	Yes / No
JZH9000-25	9000	25	0-20	75	3500	200*160*145	Yes / No
JZH9000-40	9000	40	0-32	110	4200	180*160*155	Yes / No
JZH10000-25	10000	25	0-20	75	3500	200*160*145	Yes / No
JZH10000-30	10000	30	0-24	90	3500	200*160*145	Yes / No
JZH10000-45	10000	45	0-36	132	4300	200*155*140	Yes / No

---
