Oriemac Official Mobile Telescopic Boom Lift Xgs28K 28m Aerial Working Platform Price

Product Description

ORIEMAC Official Mobile Telescopic Boom Lift XGS28K 28m Aerial Working Platform Price
Official mobile telescopic boom lift XGS28K 28m aerial working platform.
Official mobile telescopic boom lift XGS28K 28m aerial working platform features 28.2m maximum working height, 460kg maximum loading capacity, and 45% maximum gradeability. This machine is equipped with three-section telescoping boom + tower boom mechanism and is additionally installed with a jib, featuring certain obstacle-crossing capability, large working range, and extensive working scope.
With the application of double load control system, this machine can automatically adjust the working range based on the load to meet the diversified loading needs of the users and is an ideal choice for the industry users, including building construction, bridge, steel structure, and stadium interior and exterior installations.
Advantages and features:
1. The 2.4m wide platform eases the carrying of tools and materials.
2. The installation jib features certain obstacle-crossing capability and can extend to the inaccessible places.
3. The double load control system can automatically adjust the working range based on the load to meet the different loading needs of the users.
4. The synchronized luffing and lifting of the boom and column are driven by single cylinder to increase the working speed, quickly approach the working area, and improve the construction efficiency. This machine is applicable for the working areas with relatively low height and narrow space.
5. The lubrication-free bushings and sliders are applied to mitigate the friction of sliders between various connecting pins and booms, better adapt to the welding and dusty operation environments, remarkably reduce the malfunction rate, and prolong the life of the machine.
6. The four-wheel drive system, off-road wide tires, and axle balance system enable the machine to achieve excellent drive capability and road adaptability.
7. The power system adopts electronic control engine, in which the engine oil pressure, water temperature, and speed sensors are integrated and controlled by the ECU to ensure high safety and reliability and meanwhile a malfunction diagnostic interface is provided to ease the malfunction diagnosis and repairs.
8. The electric control system adopts distributed control technology based on PLC and CAN bus to realize multiple functions, including automatic leveling, platform load weighing, dynamic monitoring, and malfunction warning.

Item		Parameter
Overall dimensions	Length	12300mm
	Overall width	2490 mm
	Overall height	3050 mm
Work platform dimensions	Length Width Height	2400x900x1150mm
Wheelbase		3000mm
Maximum working height		28.2m
Maximum platform height		26.2m
Maximum working range		23.0m
Maximum carrying capacity		300 kg (Without limit)/ 460 kg (With limit)
Luffing range of boom		-5 °~ +75°
Slewing angle of turntable		360°
Tail swing of turntable (Under stowed status)		1600 mm
Slewing angle of platform		160°
Jib vertical rotation - Upward		70°
Jib vertical rotation - Downward		64°
Overall weight		18300kg
Traveling speed (Under stowed status)		6.1 km/h
Traveling speed (Lifting or expanding)		1 km/h
Minimum turn radius (Outer side)		6.7m
Minimum turn radius (Inner side)		3.6m
Minimum ground clearance		310 mm
Maximum gradeability (With counterweight end upward)		45% (24°)
Maximum gradeability (With counterweight end downward)		30% (17°)
Maximum lateral single wheel gradability		9% (5 °)
Tire specification		385/45-28
Engine model		YCF3065-T302 QSF2.8t3TC71
Engine rated power		48kw(2400r/min) 53kw(2200r/min)
Fuel tank capacity		180 L
Hydraulic oil tank capacity		210 L
Hydraulic system capacity		350 L

---
