New Hyundai Hx220HD 22ton Hydraulic Crawler Excavator

Product Description

Product Description
HX220 With Best Price and High Efficiency
* VPC variable power control system
- The VPC system provides variable pilot pressure control to ensure that operating speed matches fuel performance in all
operating modes, ensuring high efficiency and low consumption.
* Better cooling performance
- Adopt large capacity, high efficiency cooling direct fan.
- The cooling module sealing sponge is made of polyurethane sponge with higher oil resistance and heat resistance.
* Durable shaft, sleeve and resin gasket
- Increase shaft and sleeve lubricity, improve wear resistance, extend butter injection cycle.
- Suitable for resin gasket, increase side lubricity, prevent wear and abnormal noise.
- Working device looseness is minimized.
* Longer durability of structural components
- The fuel filter is suitable for the pump room and easy to maintain.
- Hi-Grade Hose with higher heat resistance and durability.
- The outer body of the muffler is suitable for aluminized steel plate, and the well uses an improved heat-resistant coating.
- The engine compartment added protective nets to make the engine compartment cleaner.
Product Parameters

Parameter	HX220L	HX230L
Operating Weight	22650 kg	23800 kg
Bucket Capacity	1.0 m³	1.2 m³
Engine Model	B7	B7
Emission Standard	Tier 4	Tier 4
Rated Power (Gross)	125 kW/168 hp/170 ps/2000 rpm	125 kW/168 hp/170 ps/2000 rpm
Rated Power (Net)	123 kW/165 hp/167 ps/2000 rpm	123 kW/165 hp/167 ps/2000 rpm
Max. Torque	746 N·m/1200 rpm	746 N·m/1200 rpm
Piston Displacement	6700 cc	6700 cc
Number of Cylinders - Bore x Stroke	6-107mm×124mm	6-107mm×124mm
Battery	2-12V×120Ah	2-12V×120Ah
Starting Motor	24V/7.5kW	24V/7.5kW
Alternator	28V/70A	28V/70A
Boom Length	5680 mm	5680 mm
Arm Length	2920 mm	2920 mm
Bucket Capacity (Standard)	1.0 m³	1.2 m³
Bucket Digging Force (ISO)[Boost]	15.4[16.7] ton	15.1[16.4] ton
Arm Digging Force (ISO)[Boost]	11.1[12.1] ton	11.1[12.0] ton
Main Pump Flow/Speed	2×234 L/min	2×234 L/min
Pilot Valve Max. Flow	18 L/min	18 L/min
Working Pressure	45 kgf/cm²	45 kgf/cm²
Main Control Valve Working Pressure	350 (380) bar	350 (380) bar
Fuel Tank Capacity	395 L	395 L
Hydraulic Tank (System)	160(225) L	160(225) L
Engine Oil	24 L	24 L
Engine Coolant	37 L	37 L
Swing Speed	11.3 rpm	11.6 rpm
Swing Torque	65 kN·m	65 kN·m
Travel Speed	5.5/3.6 km/hr	5.3/3.4 km/hr
Gradeability	35°	35°
Max. Drawbar Pull	22.6 ton	22.6 ton
Overall Length	9560 mm	9560 mm
Overall Width	2990 mm	2990 mm
Upper Structure Overall Width	2750 mm	2850 mm
Boom Overall Height	3130 mm	3130 mm
Cab Overall Height	3030 mm	3030 mm
Track Gauge	2390 mm	2390 mm
Tumbler Distance	3650 mm	3650 mm
Overall Length of Undercarriage	4445 mm	4445 mm
Track Shoe	600 mm	600 mm
Min. Ground Clearance	470 mm	470 mm
Ground Clearance of Counterweight	1050 mm	1050 mm
Tail Swing Radius	2890/2770 mm	2890/2770 mm
