Plastic Extruder Blowing Moulding Machines with Ce

Product Description

Plastic Extruder Blowing Moulding Machines with Ce
This machine can produce 2 different weight volume products with same material in the same time. PVC product will use single mould die with double mould frames.
For special machine, we can make it to order of cusiomer.
The specifications is for cusomer reference.
Small-sized Bottle Blowing Machine, small and quick, can produce all kinds of plastic bottles speedily and steadily, availed at the bottle neck outside the mould, matched with a cutting unit, a moistener, a conveying belt and an auto recovery system for breaking waste, producing 0.01-3L hollow products.
A wide variety of materials can be used for the machine, which are suitable for producing multi-type products in small batches.
Plastic Extruder Blowing Moulding Machines,equipment information.

ITEM	UNIT	TECHNICAL DATA
		ZQ-50C-2	ZQ-55C-2	ZQ-65C-2
Suitable Raw Material		PE/PP/PC	PE/PP/PC	PE/PP/PS/PC
Max. Volume of Product	L	1	2	3
Screw Diameter	mm	50	55	65
Screw L/D Ratio	L/D	25: 1	25: 1	25: 1
Screw Speed	rpm	20-60	20-60	20-90
Plasticising Capacity	Kg/h	30	45	58
Number of Heating Zone		3	3	4
Extruder Heading Power	KW	6	10	12
Die Heating Zone		2	2	3
Die Heating Power	KW	3.5	4.2	5.5
Extruder Driving Power	KW	7	11	18.5
Clamping Force	KN	35	50	70
Air Pressure	Mpa	0.6	0.6	0.7
Air Consumption	m 3 /h	0.4	0.4	0.6
Machine Weight	Kg	2000	3000	3500
Machine Dimension	m	2.6*1.8*2.2	3.0*2.1*2.2	3.2*2.3*2.2

Note: The specifications are subject to change without notice for the further improvement.
Note: Custom production accepted. Any client idea tried.,

---
