Factory Direct Sales of Small Milling Cutter Drill Integrated Grinder

Product Description

Product Description
Grinding wheel: sDcwheels used for tungsten car-bide tools, CBN wheels used for high-speed steel tools.

Model	ED-20(with fine grinding)		ED-20H(with fine grinding)
Applicable diameters	End mill φ4-φ20mm	Drill φ3-20mm
Applicable flutes	2flutes,3flutes,4flutes	Twist drills
Axial angles	Secondary clearance angle 6°,Primary rellef angle 20°,End gash angle 30°
Grinding wheel	E12SDC(or CBN)	EDCBN(or SDC)
Power	220V±10%AC
Grinding scope of the apex angle	90°-140°
Rated speed	6000rpm
Outer dimensions	370*350*380(mm)
Weight/Power	26KG/600W
Normal accessories	Collet*8pcs, 2 flutes holder*8pcs, 3 flutes holder*8pcs,4 flutes holder*8pcs, case*1pcs, Hexagon wrench *2pcs,controller*1pcs, Chuck group*1 Group

Features
End mill
1.Applicable to (2\3\4-flute) tungsten carbide and high-speed steel end mill.
2.Grind rear inclined angle, blade edge and front inclined angle.
3.For different end mill grinding, no need to change grinding wheet.
4.Easy to handle,Finish grinding in 1 minute.
5.Mill cutting edge can be adjusted sultable for materials to be processed.
Drill
1.Can grind standard twist drill of direct shank and cone shank
2.Applicable to tungsten carbide and high-speed steel drills re-sharpening
3.Length of drill to be grinded has no llmitatlon.
Company Profile
Founded in 2015, MSK (Tianjin) International Trading CO.,Ltd has grown continuously and passed Rheinland ISO 9001 authentication. With German SACCKE high-end five-axis grinding centers, German ZOLLER six-axis tool inspection center, Taiwan PALMARY machine and other international advanced manufacturing equipment, we are committed to producing high-end, professional and efficient CNC tool. Our specialty is the design and manufacturing of all kinds of solid carbide cutting tools: End mills, drills, reamers, taps and special tools. Our business philosophy is to provide our customers with comprehensive solutions that improve machining operations, increase productivity, and reduce costs. Service + Quality + Performance. Our Consultancy team also offers production know-how, with a range of physical and digital solutions to help our customers navigate safely into the future of industry 4.0. For more in-depth information on any particular area of our company, please explore our site or use the contact us section to reach out to our team directly.



FAQ
Q1: who are we?
A1: Founded in 2015, MSK (Tianjin) Cutting Technology CO.Ltd has grown continuously and passed Rheinland ISO 9001
authentication.With German SACCKE high-end five-axis grinding centers, German ZOLLER six-axis tool inspection center, Taiwan PALMARY machine and other international advanced manufacturing equipment, we are committed to producing high-end,professional and efficient CNC tool.
Q2: Are you trading company or manufacturer
A2: We are the factory of carbide tools.
Q3: Can you send products to our Forwarder in China?
A3: Yes,if you have Forwarder in China,we will glad to send products to him/her.
Q4: What terms of payment are acceptable?
A4: Normally we accept T/T.
Q5: Do you accept OEM orders?
A5: Yes, OEM and customization are available, and we also provide label printing service.
Q6: Why should you choose us?
A6:1) Cost control - purchasing high-quality products at an appropriate price.
2) Quick response - within 48 hours, professional personnel will provide you with a quote and address your concerns.
3) High quality - The company always proves with sincere intention that the products it provides are 100% high-quality.
4) After sales service and technical guidance - The company provides after-sales service and technical guidance according to customer requirements and needs.

---
