AG-60 PAO Aerosol Generator
We believe whatever you want to have about our instrument, you will find the right one you want.
AG-60 pao generator is a small, light and rugged portable, self-contained Laskin-Nozzle aerosol generator. It can generate aerosol of 10ug/l to 100ug/l with airflow 50cfm/min to 2000cfm/min. Laskin-Nozzle aerosol generators is with rugged stainless steel structure, big filling port, independent spray-head and pressure control, and normative and clean joint output. AG-60 aerosol generator has Laskin-nozzles. When with the pressure of 20 psig, it works and is diluted by the air of 200CFM,gas concentration approaching 100ug/l. Built-in control valve can make Laskin-Nozzles work to supply a wide range of aerosol concentrations.
Applications include workstations, negative-pressure filtration units, biological safety cabinets and ceiling modules, HEPA filter and more.
Specification
Air flow range
| 50 - 2,000cfm/min(1.4-56.6m3/min) built-in pump (one function)
external compress air( optional function)
|
Aerosol concentration
| 100ug/l, flow of 472.5cfm/min
|
| 10ug/l, flow of 4725cfm/min
|
Generator type
| 2-6 Laskin Nozzles
|
Aerosol type
| PAO,DOP, polydispersed
|
Compressed air
| Voltage source: build-in air compressor, no needing external air source
|
Overall dim.(mm)
| (37cm L* 26cm W *23cm H)
|
Gas type
| Varied diametric particle(cold)
|
Weight
| 15.5 KG
|
Power supply
| 220 VAC / 50H
|
Application Environment
Clean Bench Clean Room HV Built-in AC System
ULPA Filter Operating Room HEPA Filter
>>
