Diamond Drilling Core Orientation Tool

Product Description

Core orientaion tool for diamond core drilling About the CRT-2 core sample orientation instrument
2 Logging probes do the core sample orientation, and mark the line, it can be used with NQ, HQ, and PQ borehole size wireline core drilling core orientation purpose;
Specifications

DIMENSIONS
Kit
Length x Width x Height	690 x 500 x 210 mm
Weight	21kg
Downhole Instrument
Outside Diameter	55mm
Length	380mm
Weight	5kg
Handheld
Length x Width x Height	76 x 155 x 14 mm
Weight	0.24kg
ACCURACY
Range	0°to ±85°dip
Roll Accuracy	5°RMS at ±85°
BATTERY
Downhole Instrument	User replaceable, non-rechargeable lithium
Normal Use	More than 3 months
Handheld	Rechargeable lithium
Normal Use	8 hours per full charge (sleep mode may save power and increase the operation time)

Product and working Pictures

---
