Tool/Die/Mould Steel Grade Flat Plate Round Bar Block Alloy Mould Special Steel

Product Description

Product Description
YMT 8518R is a groundbreaking high alloyed Chromium-Molybdenum-Vanadium Hot Work Tool steel. Expertly engineered for the most rigorous high-pressure Light Alloys (Al-Mg) die casting dies, it complies with NADCA #207 standards, ensuring superior annealed microstructure, minimal banding segregation, and exceptional impact capability. YMT8518R is designed to achieve unparalleled performance levels. It is delivered in annealed condition with a hardness value below 230 HB.
Main features
excellent isotropy;
• high mechanical properties and strength
• high hardenability
• high thermal conductivity
• high tempering resistance;
• high thermal stability
• high thermal fatigue and hot cracking resistance;
• excellent fracture toughness in hot and cold conditions;
• high ductility
• high wear and erosion resistance
• high oxidation resistance
• required very high core temperature to optimally perform
• suitable for medium and large dies (up to 2 tons)
• suited for long run dies producing thick walled pieces
Main application
• High pressure Aluminum/Magnesium die casting molds;
• Molds for low pressure Aluminum die castings;
• Molds for Aluminum gravity die castings;
Chemical analysis

Alloy	C	Si	Mn	Cr	Mo	V
% in weight	0.32-0.40	0.10-0.30	0.30-0.50	4.80-5.50	2.00-2.40	0.40-0.70

Physical and mechanical properties
Main physical properties

	200 °C	400°C	600°C
Modulus of elasticity [MPa]	210	180	145
Coefficient of thermal expansion [10-6/K]	-	12.8	13.4
Thermal conductivity [W/m K]	-	31.0	33.0

Main mechanical properties

	400°C	500°C	600°C
Ultimate Tensile Strength (UTS) [MPa]	1200	1100	850
Yield stress (YS) [MPa]	1000	910	610
Soft annealing
Suggested temperature	850°C
Heating	Max 50°C/h
Soaking time	Minimum 120 min from the temperature settlement
Cooling	Slow in the furnace at max 25°C/h to 600°C afterward at room temperature
Stress Relieving
Suggested temperature	For material in annealed condition: 650 °C. For material in QT condition or after machining: 50°C less than the last tempering
Heating	Max 100 °C/h
Soaking time	Minimum 120 min from the temperature's settlement
Cooling	Slow in the furnace at max 25 °C/h to 200°C, afterward at room temperature
Hardening
First pre-heating temperature	400 °C
Heating	Max 150 °C/h
Soaking time	25 min every 25 mm thickness
Second pre-heating temperature	600 °C
Heating	Max 150 °C/h
Soaking time	20 min every 25 mm thickness or when (Ts-Tc) < 90 °C
Third pre-heating temperature	800 °C
Heating	Max 150 °C/h
Soaking time	20 min every 25 mm thickness or when (Ts-Tc) < 90 °C
Austenitizing temperature	980°C
Heating	> 150°C/h
Soaking time	t = ( x + 39 ) / 2 or 30 min from (Ts-Tc) < 15 °C
Cooling	Air, vacuum cooling, salt bath, polymer in water
First tempering temperature	550 °C
Soaking time	t' = 0,8 x + 120
Cooling	Room temperature
Second tempering temperature	Based on mechanical properties required
Soaking time	t" = 0,8 x + 120
Cooling	Room temperature
Third tempering temperature	30-50 °C lower than the max temperature previously used
Soaking time	t'" = 0,8 x + 180
Cooling	Slow cooling in the furnace up to 250 °C, afterward at room temperature

Chrome plating
It can be Chrome plated in order to enhance the mechanical characteristics on the surface.
In order to prevent Hydrogen embitterment, within 4 hours of Chrome plating it is advisable to carry out heat treatment at 200 °C for about 4 hours.
Nitriding
It is suitable for ionic and gas nitriding. This treatment is very useful for molds subjected to
extremely stressful applications. The increase of the surface hardness, following nitriding, extends the component life cycle.
Polishing and photo engraving
It is the suitable material when polishing and photoengraving are needed. Thanks to its integrated manufacturing process, those material manufactured by our steel mill characterized by a high degree of purity.

Certifications
Company Profile It is a comprehensive enterprise of mold raw material research and development, sales, mold base, heat reatment and other related supporting services.
Jiangsu Longchangxing New Material iechnology Co, td. was establishedin 2006. tis a comprehensive enterprise integrating research and development sales,predise miing;mold basemanufactumng, heat treatment and other relted supporting serices for mold stee. The companys ageny brands indude: Daido, Germany HE Norheast specal teel. shanghaiBaostel and otherwelknown intermationaland domestic brands of specialstel. since its establishment, the companyhas ben adherng to the tenet of"qualityas the root honesty asthe foundaton", market onented,and has won the support and trust of new and old customers from al walks of life with hioh-quality prducts and eficient senices. The company iscurrently in the leading position of the industry field.it ranks first in the.domestic applanceand automotive liahting industry in terms of sales of mold steel.
Our Advantages Engineering Solutions
Total solution for die stee
A comprehensive enterprise integrating R&D, sales, precise milling,mold base manufacturing,heat treatment and other related supporting services for mold steel.
Customer oriented
Consider cost reduction and benefit for customers
Owns its own brand of die steel,lmported quality and domestically produced prices provide you witha strong cost-reduction advantage
Craftsmen with better qualityDedication, professional, stable quality, excellent serviceFull-time inspection technicians are set up to conduct inspections at the time of purchase,inspections during production, and quality appraisals required by customers after delivery in theinherent laboratory.
German HF is a vertically integrated holding company, integrating R&D, technology andsales; its headquarters is located in Frankfurt, Germany; German HF is committed to workingwith the world's top steel mills to create high-end, high-quality tool steel and it has providedsolution for steel making and turned to be a pioneer and leader of mold steel; Hf is also oneof the main suppliers of plastic and die-casting mold materials in Europe. JiangsuLongchangxing New Material Technology Co., Ltd. is the general agent of German HF in China.

---
