Range of Application | Type of Application |
| Pharmaceutical Industry | Extraction of effective contents of Chinese herbs, concentration, refinements and precipitation of raw material drug, separation and refinements of fatty mixtures |
Foodstuff Industry | Extraction of hops, caffeine removal from coffee berry, extraction of plant pigment |
| Cosmetics & perfumery Industries | Separation and refinement of natural and synthetic perfumeries, dealkalization of tobacco, extraction of raw material cosmetics |
| Chemical Industry | Separation of hydrocarbon, refinement of organic synthetic raw material, separation of azeotrope, retrieval of raw materials of reaction, dehydration of water soluble powder of organic solution, water oxidation |
| Others | Superconducting, semiconductor, ceramics, oil washing of petroleum core, enzyme catalytic reaction, preparation of materials, superfine granules, extraction of complex compound, super critical dyeing technique, super critical reaction, super critical coating technique (pharmacy-making). |
| For Food(Fruit&nuts) | Sea buck thorn seeds oil, medlar seed oil, grape seed oil, oildophore oil of glossy ganoderma, walnut oil, fish oil, wheat embryo oil, olive oil, medlar seed oil, kiwifruit oil, seed oil of Job's tears,hemp oil, seed oil of forest frog, pine pollen oil, cauliflower oil, tea oil, etc. |
| Herb&flowers | Arteannuin, sun-drops oil, Anglica sineniss oil, chuangxiong rhizome oil, clove oil, atractylis oil, netmeg oil, zedoary turmeric oil, dahurian angelica oil, cinnamon leaf oil, ginkgo oil, men thence, schisandra oil, plantain seed oil, mother chrysanthemum oil, radix bupleuri oil, Salvia miltiorrhiza extract, herba Andrographis extract,curcuma oil pigment, bee glue, antibiotics prescipitation, lycopin, Rhizoma Alismatis oil, yolk powder phospholipid,cortex magnoliae officinalis extract, natural caffeine, Srcandra hainanensis extract,olibanum extract, cyperus oil, maloilcacid, Houttuynia cordata oil, rosemary oil, etc. |
| Spices | Gingerol, dried tiny shrimp,pepper haematochrome, haematochrome, zanthoxylum oil, allspice oil resin, onion root oil, garlic oil, hops extract, tobacco leaves essence oil, etc |
| NO | MAIN CONFIGURATION | PARAMETER | |
| 1 | Extraction Kettle | 1L, 2L, 5L/50Mpa, 10L, 24L/40Mpa, 50-200L/32Mpa, Dual purpose for solid and liquid, equipped with water jacket for circulated heating with adjustable temperature. | |
| 2 | Separation Kettle | 0.3-10L/Mpa, 50-100L/16-22Mpa, Equipped with water jacket for circulated heating with adjustable temperature. | |
| 3 | Fine Distillation Column | Inner diameter 25X2-3m/30Mpa,35X2-3m/30Mpa, 48X4-6m/30Mpa, 78X4-6m/30Mpa According to technological requirement, 4-section, 6-section or 8-section temperature control are available and relative stuffing can be selected and loaded by customer according to technological requirement. | |
| 4 | High Pressure Pump | 20L/40Mpa.h double-plunger, 50L/50Mpa.h double-plunger frequency-modulating, 400L/40Mpa.h three-plunger frequency-modulating, 800l/40Mpa.h three-plunger frequency-modulating, the pump head application. | |
| 5 | Take Pump | In the course of extraction, the entraner is used to change polarities of CO2 so as to extend range of application. | |
| 6 | Cooling System | Equipped with semi-sealed or full-sealed compressor to meet technological requirement. | |
| 7 | Heat Exchange and Temperature Control System | According to technological requirement, the heat exchange and temperature control system are equipped for extraction kettle, separtion kettle and fine distillation column respectively to control the temperature of water circulation at -85ºC and the temperature pf oil circulation at -150ºC; the digital display double-screen is used to control the temperature of water bath and to measure the temperature of CO2 fluid with accuracy of temperatire control at ±1ºC. | |
| 8 | Pressure Control (Protection) | Equipped with the electro connecting pressure gauge at the outlet of the high pressure pump and set the working prssure to release pressure and make automatic protection in case overpressure occurs; equipped with safety valves for high pressure pump, extraction kettle, separtio kettle, fine distillation column according to their maximum working pressure to release pressure and make automatic protection in case overpressure occurs; equipped with back-pressure valve system at the outlet of the extraction kettle which has stable pressure and is easy to make adjustment. The control accuracy of pressure (dynamic) is ± 0.1MPa. | |
| 9 | Display of Flow | The metal rotor flow meter with remote transferable digital display for instant flow and accumulated flow respectively. | |
| 10 | Pipelines | All containers, valves, pipe fittings and pipelines contacting with fluid are all made of stainless steel. | |
| 11 | Others | Three-phase-four-wire power supply with 380V/50Hz and CO2 with foodstuff grade ≥99.5% are prepared by customer itself. | |
| Capacity | Model | Extractors and separators | |
| 1 | 0.5L | Model 0.5Lx1/50MPa | 1 Extraction 2 Separation |
| 2 | 1L | Model 1Lx1/50MPa | 1 Extraction 2 Separation |
| 3 | 2L | Model 2Lx1/50MPa | 1 Extraction 2 Separation |
| 4 | 5L | Model 5Lx1/50MPa | 1 Extraction 2 Separation |
| 5 | 5L+1L | Model 5L+1L/50MPa | 2 Extraction 2 Separation |
| 6 | 10L | Model 5Lx2/50MPa | 2 Extraction 2 Separation |
| 7 | 20L | Model 10Lx2/40MPa | 2 Extraction 2 Separation |
| 8 | 50L | Model 25Lx2/40MPa | 2 Extraction 2 Separation |
| 9 | 100L-1 | Model 25Lx4/40MPa | 4 Extraction 2 Separation |
| 10 | 180L | Model 30Lx6/40MPa | 6 Extraction 3 Separation |
| 11 | 100L-2 | Model 50Lx2/40MPa | 2 Extraction 2 Separation |
| 12 | 200L | Model 50Lx4/40MPa | 4 Extraction 3 Separation |
| 13 | 300L-1 | Model 150Lx2/40MPa | 2 Extraction 3 Separation |
| 14 | 300L-2 | Model 50Lx6/40MPa | 6 Extraction 3 Separation |
| 15 | 150Lx4 | Model 150Lx4/40MPa | 4 Extraction 3 Separation |
| 16 | 300Lx4 | Model 300Lx4/35MPa | 4 Extraction 3 Separation |
| 17 | 1000Lx2 | Model 1000Lx2/35MPa | 2 Extraction 3 Separation |
| 18 | 1500Lx2 | Model 1500Lx2/35MPa | 2 Extraction 3 Separation |
| 19 | 2000Lx2 | Model 2000Lx2/35MPa | 2 Extraction 3 Separation |
| 20 | 3000Lx2 | Model 3000Lx2/35MPa | 2 Extraction 3 Separation |
| 21 | 150Lx3 | Model 150Lx3/35MPa | 3 Extraction 3 Separation |
| 22 | 300Lx3 | Model 300Lx3/35MPa | 3 Extraction 3 Separation |
| 23 | 500Lx3 | Model 500Lx3/35MPa | 3 Extraction 3 Separation |
| 24 | 600Lx3 | Model 600Lx3/35MPa | 3 Extraction 3 Separation |
| 25 | 1000Lx3 | Model 1000Lx3/35MPa | 3 Extraction 3 Separation |
| 26 | 1500Lx3 | Model 1500Lx3/35MPa | 3 Extraction 3 Separation |
| 27 | 2000Lx3 | Model 2000Lx3/35MPa | 3 Extraction 3 Separation |
| 28 | 3000Lx3 | Model 3000Lx3/35MPa | 3 Extraction 3 Separation |
| CUSTOMIZED MODELS ARE AVAILABLE FOR DIFFERENT PRESSURES AND VOLUMES. | |||
