| US$2,000.00-10,000.00 | 1 Piece (MOQ) |
| Item | Z3050×16 | Z3050×14 |
| Max.drilling dia. mm | 50 | 50 |
| Distance from spindle nose to table surface mm | 260-1050 | 260-1150 |
| Distance between spindle axis and column surface | 360-1600 | 360-1400 |
| Spindle travel mm | 220 | 220 |
| Spindle Cone MT | 5 | 5 |
| Spindle speeds range (r.p.m) | 78.135.240. 350.590.1100 | 78.135.240. 350.590.1100 |
| Spindle speed step | 6 | 6 |
| Spindle feeding step r.p.m | 2.10-0.56 | 0.10-0.56 |
| Spindle feeding step | 3 | 6 |
| Rocker rotary angle | 360 | 360 |
| Main motor power kW | 4 | 4 |
| Movement motor power kW | 1.5 | 1.5 |
| N.W./G.W./ kg | 2800 | 2400 |
| Overall dimensions mm | 2170×950×2450 | 1950×810×2450 |
