Introduction to Marine Electric Hoisting Winches
The electric lifting winch is composed of an electric motor, a drum, a frame, etc. Powered by a marine electric motor, driven by couplings, gear reducers, large and small gears, and clutches, the drum rotates using various types of brakes such as electromagnetic/hydraulic, and equipped with manual band brakes and manual clutches.
The product has a compact structure, small size, light weight, large lifting capacity, and convenient use, and is widely used in various lifting equipment such as ships, oil fields, coal mines, ports, etc.
Technical Data of Marine Electric Hoisting Winches:
model
| RATS150-110-00
|
brand
| xinrongan
|
First layer rated load
| 150KN
|
Drum capacity
| 60m
|
Average rope speed
| 5m/min
|
Number of layers of wire rope winding
| 2Number of layers
|
Wire rope diameter
| 30mm
|
Reel
| diameter
| 720mm
|
width
| 650mm
|
Height
| 600mm
|
reduction ratio
| 215
|
motor
| model
| YBS-H-B35
|
power
| 55KW
|
speed
| 970 rpm
|
voltage
| 380V
|
Overall dimensions
| length
| 2310mm
|
width
| 1130mm
|
height
| 1350mm
|
