High Speed Paper Cup/Bowl Machine (ZSZB-D)

Product Description

High Speed Paper Cup/Bowl Machine (ZSZB-D)
ZSZB-D Single side PE coated paper cups are widely used for hot drinks( hot coffee cups, hot water), some cold drinks(ice-cream cups). One side PE coated paper cups is not suitable for some certain beverage: coca-cola, coke, cold beer. The reason is when a certain beverage or cold beverage filling in one side PE coated paper cups, the paper become softened and the water will leak out slowly.
IF you really want to produce the cups filling beverage or cold drinks, recommend you use double PE coated paper cups produced by double sides PE coated paper cup machine(with Ultrasonic hot-pressing system)
Main Feature:
1.The capacity is increased to 65-75 cups per minute from 45-55 cups per minute.
2.Open Gear driving system is adopted instead of chain driving to avoid chain loosed and broken.
3.It adopts PLC system,HMI computer operation,sensor detecting system.All of the electrical equipments use LG from Korea.
4.The machine host uses automatic lubrication system.It is convenient to be well maintained and good for working life..
5.The bottom paper feeding is controlled by stepping-motor (or equipped with servo-motor) and sensor.The feeding length is adjusted quickly and accurately, and reduce paper waste.

Container Capacities	6oz~24oz(150cc~700cc)
Speed	55-80cups/min
Maximum container dimensions	Max top diameter:145mm Max cup height:178mm
Minimum container dimensions	Min top diameter:50mm Min cup height:50mm
Electric Power	380V or 220V,50Hz or 60Hz 3P
Weight	2500kgs
Dimension	2600mm*1350mm*1700mm
Electrical box	600*500*1000mm

Our Service:
1.Spare parts guarantee for one year in machine arrival.
2.Send the technician for installation & training.
3.Offer Service Online
FAQ:
1.Q:Are your company a manufacturer or trading company?
A:We are a manufacturer with ten years of exporting experience by own trading company

2.Q:Where is your factory? How can I get there?
A:Our factory is located in wenzhou City, Zhejiang Province. It takes about one and a half hours by train from Shanghai to our city. all of our customers can take the flight to wenzhou international airport first, and then we can send a car to pick up you.

3.Q:Can your products be customized?
A: Almost all of our products can be customized, including the sizes, color, logo, package and so on. OEM orders are highly welcome.

4.Q . how's the delivery time ?
A. Usually it will take about 3-4 weeks for production,all of our machinery shall be packed well with film to be water proof, and then loading and fix in a wooden case
If you are interesting in our machine,please feel free to contract with us:
Mobile:+86 13819753964

Website:daqiao3066.en.made-in-china.com

---
