| EN14683 | ASTM F2100, ASTM F2101 | ||
| Note: For more standards, please contact us | |||
| Model | AT920 | ||
Enterclose A | Sampling flow | 28.3 L/min | |
| Resolution | 0.1L/min | ||
| Tolerance | ±2.5% | ||
Enterclose B | Sampling flow | 28.3 L/min | |
| Resolution | 0.1L/min | ||
| Tolerance | ±2.5% | ||
Spray system | Flow rate | 8~10L/min | |
| Resolution | 0.1L/min | ||
| Tolerance | ±5.0% | ||
Peristaltic pump | Flow rate | 0.006 ~3 ml/min | |
| Resolution | 0.001 mL/min | ||
| Tolerance | ±2.5% | ||
Pressure in the forepart of flow-meter for Enterclose A/B | Pressure range | -20 ~ 0kpa | |
| Resolution | 0.01kpa | ||
| Tolerance | ±2.5% | ||
Pressure in the forepart of flow-meter for Spray system | Pressure range | 0 ~ 300kpa | |
| Resolution | 0.1kpa | ||
| Tolerance | ±2.5% | ||
Aerial fog negative pressure | Pressure range | -90 ~ -120kpa | |
| Resolution | 0.1Pa | ||
| Tolerance | ±2.0% | ||
| Operating temperature | 0 ~ 50℃ | ||
| Biosafety zone negative pressure | -90 ~ -120 Pa | ||
| Data storage capacity | 20G | ||
| Data output and interface | USB (3 interfaces) | ||
| High efficiency air filter performance | ≥99.995%@0.3μm, ≥99.9995%@0.12μm | ||
| Total number of positive quality control sampler particles | 2200±500 cfu | ||
Aerosol generator mass median diameter | Average particle diameter (3.0±0.3μm), Geometric standard deviation≤1.5 | ||
Six-stage Anderson sampler captures particle size | Level 1(>7 μm); Level 2(4.7~7 μm); Level 3(3.3~4.7 μm); Level 4(2.1~3.3 μm); Level 5(1.1~2.1 μm); Level 6(0.3~1.1 μm) | ||
| Aerosol chamber | Length 600 * Diameter 80 * Thickness 3.0 mm | ||
| Ventilation flow of negative pressure cabinet | >5m³/min | ||
| Working noise | <65db | ||
| Power supply | 220V, 50Hz | ||
| Dimension | 1250*700*2000 mm | ||
| Work area | 870*600*1100 mm | ||
| Net weight | Around 250kg | ||
| Packaging | ||
| Dimensions | 1300*980*1510mm (LWH) | |
| Weight | Approx. 200kg | |
Packaging Details | 1. The equipment is covered with film is protect it from water vapour during the trip. 2. The box is filled with foam to protect the equipment from impact. 3. Exported wooden box made from plywood, don't need fumigated. | |
Payment Term | T/T | EXW | 30% T/T in advance, paid the balance before shipment | ||
| FOB | |||||
| CFR(C&F) | 30% T/T in advance, paid the balance against copy of B/L | ||||
| CIF | |||||
| L/C | L/C amount above 50,000 usd, we can accept L/C at sight | ||||
| West Union | Amount lower than 5000usd | ||||
| West Union | |||||
| Delivery Time | 7~10days after receiving payment for one container | ||||
