High Temperature Polyester Cotton Fabric Jet Dyeing Machine

Product Description

High temperature High pressure Jet Dyeing Machine
Product Description
High temperature High pressure Jet Dyeing Machine is the classic jet dyeing machine model which has wider applicability. It is mainly used for dyeing and pretreatment of nature or synthetic fabric, mixed spined fabric (T/C,T/R,T/W), cotton, rayon, polyester, nylon, tencel, etc.
Special Features
- Classic design, wider applicability
- Ultra low lifting reel for very low tension of the fabric
- Fabric opening device to avoid crease marks
- Anti-twisting device
Technical Details
- Main tank & liquor carrying parts are made of stainless steels 316L
- Chamber capacity around 250 kg
- Available with up to 4 chambers per machine
- Liquor ratio starts at 1:6
- Fabric winch drive max. 600m/min, depending on fabric properties
- Adjustable winch speed
- Maximum operating temperature 140ºC
- Touch screen controller
- Electro-pneumatic operated valves
- Frequency controlled pump motor & winch
- Control cabinet in stainless steel
- Adjustable nozzle pressure
- Adjustable round nozzle
- Automatic seam detector
- Rope circulation control
- Water meter Fully automatic dosing
- Unloading winch & plaiter
Optional
- Second preparation tank
- 100% Hot water stock tank, preparation of the complete process bath
- Auto self-cleaning filter
- Fast dosing system, bypass function
Technical Specifications

Item Model			JED I	JED II	JED IV
Max Pressure(kg/cm²)			4	4	4
Max Temperature(ºC)			140	140	140
Capacity(kg)			125-250	250-500	500-1000
Main Pump Power(kw)			22	37	75
Fabric Speed(m/min)			150-600	150-600	150-600
Dimension	Length	L1	9140	9140	9140
		L2	10800	10800	10800
	Width	W	1520	2680	5120
	Height	H1	1720	1720	1720
		H2	3060	3060	3060

Note: Specifications of above machines are only for reference. The company reserves the right of alteration.

Machine Picture

---
