Rotating Screener Rotary Vibrating Seive (PKZX)

Product Description

About Us Headquartered in Xinxiang City, Henan Province, China, domestic well-known screening and conveying equipment city, PK Machinery has enjoyed more than 50 steady years of successful growth, and now it has been widely acknowledged as a trustworthy and professional manufacturer in the field of bulk material handling equipment, including vibrating screen, vibrating feeder, belt conveyor, bucket elevator, screw conveyor, scraper chain conveyor and associated spare parts in complete specifications.
Product Description
Product Description of circular sifter (round sifter)
Introduction
Rotary vibrating screen is designed as a high-precision screening machinery, it is composed of a upper cover, a screen box, a base and a vertical motor with eccentric weight installed at two ends. Rotary vibrating screen can be produced in horizontal, vertical, inclined motions by adjusting the upper and lower eccentric weight. Diameter also can be ranged from 400mm to 2000mm, with single or multiple screening decks, material can be total carbon steel, total stainless steel or material contact parts are stainless steel according to different product.
Working Principle
The vibration is accomplished by eccentric weights on the upper and lower ends of the motion-generator shaft. The direction of the eccentric weights can change its rotational mode,rotation of the upper weight creates vibration in the horizontal plane, which causes material to move across the screen cloth to the periphery,while the lower weight acts to tilt the machine, causing vibration in the vertical and tangential planes. The trajectories of materials on the screen can be changed by adjusting the phase angle of upper and lower weights.
Application
Rotary Vibrating Screen is widely used in many industries, covering food, chemical, ceramic, metallurgy, pollution treatment and so on, dealing with various kinds of materials.
Features of circular sifter (round type sifter):
1. Stainless circular sifter can satisfy different process requirements because of its special vibration type and the adjustment of the material trajectory and amplitude.
2. Any particle, powder, slurry can be filtered and screened.
3. High efficiency, both rough grading and fine screening can filter;
4. Small size, light weight, easy to move and install;
5. Special screen design, easy to change; Long life, easy to clean, simple to operate;
6. Fully closed, no dust is beneficial of improving working conditions;
7. Discharging coarse and fine material can grade automatically and reach automatic operation; - energy consumption, low noise, saving energy.
Application of circular sifter:
It is widely used in chemical industry, food industry, metal, metallurgy, mining industries, pollution treatment, etc.
Diameter of circular sifter: 400mm-1800mm
Layers No.: 1-5 layers Product Parameters Technical Parameters

Model	Nominal Diameter(mm)	Screen Diameter(mm)	Screen Surface Area(m3)	Feeding size (mm)	Specification	NO. of Layers	Frequency(rpm)	Power(Kw)
XZ-400	400	340	0.09	<10	2-325	1-5	1500	0.18
XZ-600	600	530	0.22	<10				0.25
XZ-800	800	720	0.4	<20				0.55
XZ-1000	1000	900	0.63	<20				0.75
XZ-1200	1200	1100	0.95	<20				1.1
XZ-1500	1500	1400	1.5	<20				1.5
XZ-1800	1800	1710	2.3	<30				2.2
XZ-2000	2000	1910	2.86	<30				3.7

Note: the parameter above is just for reference,it can be customized by different requirment.
Producing Spot

---
