Yzyx Type Oil Press Spare Parts Quick-Wear Part for Oil Expeller

Product Description

YZYX type oil press spare parts quick-wear part for oil expeller
Scope of application:
Peanut, soyabean ,Rapeseed ,Cottonseed, Sesame, Sunflower seed, flax ,castor, corn germ,Tea seed, palm kernel, shea, Shea fruit, Pomegranate seeds , coffee beans,cocoa beans, hodgsonia, Grape seed etc.More than 40 kinds oil crops.
Features of spiral oil press:
1. The screw oil press has high oil yield, strong adaptability, and can operate continuously, with a large single machine processing capacity
2. The clearance between the oil lines of the spiral oil press is small, reducing the amount of slag, increasing the pressure of the press chamber, and improving the oil output rate.
3. Dynamic pressing and squeezing, friction heating, short pressing time, fast oil delivery, Sanbang oil press; Product Description

TYPE	YZYX10(95)	YZYX120	YZYX130
Capacity	3.5-4T/D	6.5T/D	8T/D
Motor	7.5 or 11KW	11 or 15KW	15 or 18.5KW
Screw diameter	φ 95mm	φ 120mm	φ 130mm
Screw speed	32-40r/min	28-40r/min	30-40r/min
Oil Content of dry cakes	<=7.6%	<=7%	<=7.6%
Weight	528Kg	680Kg	825Kg
Equipment size	1650*730*1340mm	1860*740*1275mm	2020*742*1420mm

1

TYPE	YZYX140GX	YZYX140CJ	YZYX140CJGX
Capacity	9-11T/D	9-11T/D	9-11T/D
Motor	18.5 or 22KW	22KW	22KW
Screw diameter	φ 140mm	φ 140mm	φ 140mm
Screw speed	30-40r/min	32-40r/min	30-40r/min
Oil Content of dry cakes	<=7.6%	<=7.6%	<=7.6%
Weight	1000Kg	980Kg	1100Kg
Equipment size	2150*820*1420mm	2150*750*1420mm	2300*820*1420mm

2

TYPE	YZYX168
Capacity	20T/D
Motor	37 or 45KW
Feeding power	0.55-1.1kw
Screw diameter	φ 168mm
Screw speed	36-44r/min
Oil Content of dry cakes	<=6.3%
Weight	1820Kg
Equipment size	2750*1100*1830mm

Detailed Photos
