Klt-T4K-Ov13850 V2.0 13MP Ov13850 Mipi-Schnittstelle Autofokus Kameramodul

Product Description

13MP OV13850 MIPI-Schnittstelle Autofokus Kameramodul
Kameramodul Nr. KLT-T4K-OV13850 V2.0

Kameramodul Nr.	KLT-T4K-OV13850 V2.0
Auflösung	13MP
Bildsensor	OV13850
Sensorart	1/3.06"
Pixel Größe	1.12 um x 1.12 um
EFL	3.81 mm
F.NO	2.20
Pixel	4224 x 3136
Betrachtungswinkel	74.4°(DFOV) 62.7°(HFOV) 48.7°(VFOV)
Linsenabmessungen	8.50 x 8.50 x 5.60 mm
Modulgröße	163.00 x 8.50 mm
Modultyp	Autofokus
Schnittstelle	MIPI
Autofokus-VCM-Treiber-IC	DW9714P
Linsenmodell	KLT-LENS-50013A1
Linsentyp	650 nm IR-Schnitt
Betriebstemperatur	-30°C to +85°C
Gegenstecker	AXE530124
