Lk Potenza-III 560 Ton High Precision Servo Injection Molding Machine

Product Description

Brief Introduction
LK group specializes in the design manufacture and sales of die casting machines, high precision injection molding machines, CNC machine centers, and industrial integrated control systems. Our market share of die casting machines is over 60%, the injection molding machine ranks among the top 3 in China.
We have more than 10 production bases worldwide, most in domestic China, 1 in Taiwan and 1 acquired company IDRA in Italy, it is one of the world's leading die casting machine manufacturers. Our injection molding machine centers are Zhongshan in Guangdong and Ningbo in Zhejiang.
There are over 60 sales and service centers in the world with high-quality after-sales service. Our 24-hour prompt response system provide all-around fully coverage customer service.
Key features
1. Enlarged design of the mode-locking structure
2. The whole machine layout is reasonable, the shape line is firm
3. The momentum is strong and the cycle is shorter
4. High response, low noise hydraulic system
5. High precision linear guide injection unit
6. Add cloud injection molding network interface
Use of application
Power Tool, Personal Care, Toys, Electrical Appliances, Body Parts, Steering Wheels, Small Packaging, Daily product
Main Performance Feature
1. Highly optimized clamping unit
2. Low energy consumption design
3. Stable, precise screw linear motion
4. Unique PLC with comprehensive functions.
Technical Parameter List

	ITEM	UNIT	PT560
Shooting Part	Shot Weight(ps)	g	1708	2194	2459	3036
	Screw Diameter	mm	75	85	90	100
	Injection Volume	cm^3	1876	2410	2702	3336
	Injection Pressure	Mpa	209	163	145	118
	Screw L/D Ratio	L/D	23.8	21	19.8	17.8
	Injection Rate	cm^3/s	530	680	763	942
	Plasticizing Capacity(ps)	kg/hr	208	248	284	346
	Screw Speed	r/min	160
	Hopper Capacity	L	125
Clamping Part	Locking Force	KN	5600
	Die Height(Min-Max)	mm	350-850
	Opening Stroke	mm	850
	Space Between Tie Bars	mm	860*860
	Ejector Stroke	mm	240
	Ejector Force	KN	166
Others	Motor Capacity	KW	35.6*2
	Max. Working Pressure	Mpa	17.5
	Oil Tank Capacity	L	890
	Heating Capacity	KW	39.2

Products Display
Showroom Review
Factory Review

---
