DLS400 FINCM CNC Hydraulic Steel Structure Band Sawing Drilling Machine For U Channel

Product Description

Product Description
DLS400 FINCM H-Beams Band CNC Sawing Drilling Machine
Steel Structure Beam Drilling and Sawing Combined Machine Line.Mainly used for drilling holes on H beam and Channels. It can be mass production of multiple varieties .
Machine composition:
1) Feeding support rolling table:1 set ;
2) Feeding trolley:1set;
3) Three-dimensional CNC drilling machine(SWZ400/9):1set;
4) Corner band saw machine(DJ500):1 set;
5) discharge support rolling table :1 set;
6) electric systems :1set ;

Note: DJ on the left, SWZ on the right
Equipment advantages:
Fabricated by strong welded steel plate and steel profile, after enough heat treatment procedure, with good enough rigidity and quite reliable performance.
Fabricated by strong welded steel plate and steel profile, after enough heat treatment procedure, with good enough rigidity and quite reliable performance.
The automatic web height and flange width measuring device can compensate the drilling operation's tolerance if any caused by irregular contour of material profile, which assures higher working accuracy.

There is photoelectric focusing switch at the feeding portal of the machine, fast get the benchmark at feeding direction, it can assure very high feeding position accuracy even after long time's operation.

The software can automatically create processing program by directly reading the drawing (with stipulated format), the operator just needs to simply input the material size, without complicated program edition, which is very convenient for machine's operation, greatly improves the production efficiency.
Process flow:
1,Place multiple workpieces on the feeding support roller table, push sideways to ensure that the workpieces are close to the reference
2,Manually assisted manipulator clamping workpiece web
3,Input processing program, start automatic processing, complete drilling and sawing (manual removal of waste) procedures
4,The manual button controls the work of the electric roller on the discharging support roller table and conveys the workpiece to the unloading position.
Catalog of main purchased parts:

No.	Name	Band	Country
1	PLC	Inowance	China
2	Linear guides	HIWIN/CSK	Taiwan
3	Servo motor	Inowance	China
4	Server driver	Inowance	China
5	Control valve	ATOS	Italy
6	Hydraulic valve	ATOS/Yuken	Italy
7	Hydraulic pump	Justmark	Taiwan
8	Hydraulic valve	Yuken/Justmark	Japan/Taiwan
9	Linear guides	HIWIN/PMI	Taiwan
10	Band saw blade	WIKUS/Renault	German/USA

Company Profile

Shandong FIN CNC MACHINE CO., LTD. is always focusing on our ultimate goal - to secure and increase our customer's productivity - has made us the leader in China market in the manufacture of machines for processing angle bar, beam channel profiles, steel plates, tubesheet and flanges, mainly serving for fabricating iron towers, steel structure, heat exchangers, boilers, bridges, and trucks.Strong R & D center with 30 engineers team, 24 years of experience from year 1997, 280 staff, plant area about 270,000 sqm., very harsh quality control of every component and the whole machine, about 40 million US dollars sales turnover per year.
FIN CNC machines' market share in China is around 70% and exported to 50+ countries across globe market. All top ranked tower manufacturers, steel structure fabricators and power station makers, bridge/railway manufacturers, truck makers are our clients.
Main products: CNC Angle Line, CNC Beam Drilling Sawing Machine, CNC Plate Drilling Machine, CNC Rail Processing Machine, CNC Tubesheet Flange Drilling Machine, Truck beam plate punching machine, etc..One measure of the outstanding quality of our machines is their longevity: many FIN machines have been in operation for more than 17 years! Many clients are continually placing repeated orders which verified well our machines' perfect quality and reliable performance.
The company drafted many China national standards for CNC angle line machine and CNC beam drilling sawing machine and CNC plate drilling machine.
Product Process Control
Customer Praise

Sales Network

FAQ
1. When can you arrange shipment?
For machines available in stock, the shipment can be arranged within 15 days after getting advance payment or L/C;
For machines non available in stock, the shipment can be arranged with 60 days after getting advance payment or L/C.
2. What can you do if my machines have problems?
1) We can send you free components if machines are in warranty period;
2) 24 hours service on line;
3) We can assign our engineers to serve you if you want.
3. Do you provide machine operation training?
Yes. We can send professional engineers to the working site for machine's installation, commissioning and operation training.
4. Which machine model shall I choose when I purchase from you?
Please share us your material size and your processing request, then we will recommend our machine most suitable and most cost effective for your work demand.
5. What's your machine's market share in China?
Our market share in China is about 70%+, and we've exported to 50+ countries across the globe market, since year 1998.

---
