Dongfeng 4X2 6cbm Skip Loader Truck Garbage Trucks 6cbm Skip Bins

Product Description

Product Description Dongfeng 4x2 6cbm Refuse truck
Garbage truck is mainly used in municipal sanitation and large factories and transport all kinds of rubbish, especially suitable for transportation community living garbage.
We provide various types of waste collection vehicles such as side loader, refuse compactor, swing-arm garbage truck, arm-roll garbage truck, sealing dump garbage truck, compression docking refuse collector, kitchen waste truck, etc.
1. Dustbin volume:4~20CBM.
2. Chassis brand: Dongfeng,SINOTRUK,JAC,FAW,FOTON etc.
3. Drive type:4*2, 6*4,8*4
4. Engine:120/
160/180/210/290HP
5. Emission standard:Euro 2/Euro 3/Euro 4/Euro 5.
6. With 3C and passes the ISO9001-2008,SGS.
7.The swing arm garbage truck can be used for multiple dustbins with dump function.
8. OEM, We are a professional manufacturer and can produce all kinds of sizes for swing arm garbage truck.

Detailed Photos

Product Parameters

Cabin	Driving type 4x2
	H5 Cabin with two seats, with A/C. Left Hand Driven. 70°hydraulically tillable to the front as attached photo for ref.
Vehicle Main Dimensions	Overall dimensions (L x W x H)mm	9000x2500x3500
	Wheel base (mm)	4600
	Wheel track (front/rear) (mm)	1980/1860
	Approach/Departure angle(°)	24/15
Weight in KGS	Tare Weight	8500
	Loading Capacity	12000
	Front axles loading capacity	1×6000
	Rear axles loading capacity	1x12000
Max. driving speed(km/h)		90
Engine	Brand	YUCHAI
	Model	YC6J220-33
	Type	4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling
	Horse Power(HP)	220 HP
	Emission standard	Euro 3
Gearbox	DC6J65TC, 6 forwards &1 reverse
Clutch	Reinforced diaphragm clutch, diameter 430mm
Steering Gear	hydraulic steering with power assistance
Fuel tank (L)	300 L
Tire	10.00R20 tires with one spare, totally 7 pcs.
Swing arm system with cargo box
Garbage cargo box :12CBM , Carbon steel material , underground type or aboveground type can be optional. PTO motivated hydraulic system, two hydraulic cylinders with lifting arm and two hydraulic cylinders with landing leg Swing arm maximum pivot angle 145 ; hoisting time 30s ; Unloading time 50s.

Company Profile
1. CHUSHENG VEHICLE GROUP CO.,LTD. is a famous and the biggest manufacturer with very professional experience in special
automobile field for more than 20 years in China. We have more than 3000 workers, 400 technicians, and factory scale is more
than 690,000m2.
2. Our most advantage and leading products including LPG tanker series, Water Tank Truck, Fuel tank Truck, Refrigerated Truck,
Garbage Truck, Towing/Wrecker truck, Dump Truck, Sewage Suction Truck, Concrete Mixer Truck, Bulk Cement Truck, Van Truck,
Sweeper Truck, Truck with Crane, Fire fighting Truck, High-altitude Operation Truck, Chemical Liquid Truck, Milk Transport Truck,
LED Display Truck, Various Semi-trailer, Spare parts etc.
3. We have successfully exported to more than 60 countries, such as Ghana, Togo, Sudan, Kuwait, Peru, Nigeria, Benin, Angola,
Tajikstan, Azerbaijan, Namibia, Burma, Korea, Iran, Afghanistan, Iraq, Philippines, Vietnam, Saudi Arabia, Mexico, Chile, Bolivia,
Tanzania, Zambia, Zimbabwe, Yemen etc. Our product have passed the ISO9001 quality system certification, and CCC certificate.
Our Services Pre-sale service:
1. Reply enquiries in 24 hours.
2. Market research and forecast for customer.
3. Provide unique and professional solutions based on customer's requirement.
4. Data sheet and samples offer.
5. Other services, such as special packing design, factory visiting and so on.
In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.
3. Photos and videos as per customer's requirement.
4. Free spare parts.
After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
6. Special service for big project, such as stadium, exhibitions, squares and so on.

FAQ Q1 : Are your manufacturer ?
A1: Yes. We can totally manufacture the trucks as you required.
Q2: How to ensure product quality?
A2: Firstly, we passed the international quality system certification. Secondly, Aliba ba Group has conducted field certification for our factory.
Finally, you can entrust third party individuals or organizations to inspect our products before delivery.
Q3: Do you have a good organization of shipping vessle?
A3: Yes, we have a good and long term cooperation with the world first class famous shipping company line, like MSK,PIL, SUNSHINE SHIPPING, ETC.
The order over 500 units of vehicle, we will lease a vessel.
Q4: How about your warranty items?
A4: We supply original spare parts of our vehicles, if you need, we will show you spare parts list for your choosing to make sure daily maintain of your vehicles.
Q5: Can I be your agent in my country?
A5: It is Ok if the order is appropriate, we looks forward to long-term cooperation with you.
Contact us Wanna more information about our trucks, please kindly contact:
Ms Lilia
CHUSHENG VEHICLE GROUP CO.,LTD.
Factory: NO.9, Jiliang Avenue, Suizhou Economic Development Zone,Suizhou,Hubei,China
Office: Room 1108, Eurasia Plaza,No.20 Jinyinhu Road, East- west lake District,Wuhan,Hubei,China.
