Product Details
Product Description
Product Description
Introduction Of Commercial Kitchen Equipment For Mcdonald And Kfc French Fries Gas Deep Fryer Machine
The potato chip french fries processing equipment produced by our company realizes the fully automatic production from cleaning and peeling to packaging. It is made of all stainless steel, and the stainless steel selected is in line with food-grade stainless steel. It is easy to operate, truly fully automatic, saves labor, and also saves energy. It has a small footprint, convenient maintenance and perfect after-sales.
Process and equipment introduction Of Low Price Full Automatic Potato Chips Machine Production Line From Factory
1. Lifting machine: lifting materials into the peeling machine
2. Washing and peeling machine: After the potatoes come in, they are washed and peeled, feeding and discharging at the same time, fully automatic
3. Picking line: Pick the potatoes that have been cleaned and peeled, and pick out the bad potatoes.
4. Lifter: Lift the cleaned and peeled potatoes into the slicer.
5. Potato chips and fries machine: Put the peeled and clean potatoes into the feeding port continuously, and the chips and fries will be automatically cut out.
6. Rinse line: Clean the cut potato chips and French fries to wash away the starch on the surface.
7. Boiling line: blanch the potato chips and fries to fix the color to prevent oxidation and blackening.
8. Air-cooled dehydrator: Blow the water on the surface of the blanched potato chips and fries to dry them for frying.
9. Deep-fried assembly line: Deep-fried potato chips and fries.
10. De-oiling line: remove the oil on the surface of the fried potato chips and fries.
11. Seasoning line: season the fried potato chips and French fries.
12. pick out unqualified potato chips and fries.
13. Packaging machine: Packaging potato chips and French fries.
Parameter Of Hot sale french fries potato chips french fries production line
| 1 | Different machines for making potato chips or french fries |
| 2 | Small, medium and large capacity from 100kg/h, 300kg/h, to 1000kg/h, 2000kg/h output and workflow can be customized |
| 3 | Semi automatic or fully automatic processing machines |
| 4 | Electricity or gas, diesel heating source for blanching and frying machine. |
| 5 | The size of french fries and the thickness of potato chips are adjustable. |
| 6 | For french fries line, we have special equipment to remove the unqualified fries. |
| 7 | All machines are made of SUS304, Schneider electrical components and Siemens brand motor. |
| 8 | With special designed fryer, quick heating and energy saving, enabled good performance |
| Model | semi20-30kg | semi60kg | semi150kg | auto60kg | auto150kg | auto300kg |
| Power | 40kw | 65kw | 104kw | 153kw | 224kw | 296kw |
| Voltage | 220v/50hz | 380v/50hz | 380v/50hz | 380v/50hz | 380v/50hz | 380v/50hz |
| Capacity | 20-30kg/h | 60kg/h | 150kg/h | 60kg/h | 150kg/h | 300kg/h |
| weight | 1260KG | 1780KG | 2780KG | 7800KG | 9800KG | 12000KG |
| size | 8.5*1*1.5m | 11*1.2*1.5m | 13*1.6*1.6m | 40*1.2*2.3m | 45*1.2*2.3m | 55*1.2*2.3m |
Features of Good price with french fries french fries production line frozen french fries making machine
All the equipment of potato chips french fries potato pellets chips making machine have flow operation, high automation degree, large output, and have low one-time investment, low energy consumption,cover an area of an area small, convenient usage and maintenance, finished goods quality, high profit, etc.The whole production line respectively by cleaning peeling, slicing (article), washing, blanching, rinse, dehydration, frying, deoiling, flavor,packaging, etc. We can provide free formulation and technical guidance, to make sure that you fry out high quality chips of chips.If need frozen line, plus a quick-freezing machine.The entire assembly line consists of cleaning, peeling, slicing (striping), washing, blanching, rinsing, dehydration,frying,deoiling, seasoning, packaging and other processes.
The complete set of equipment of potato chips french fries potato pellets chips making machine consists of cleaning, slicing (stripes), blanching, dehydration, oil-water mixed frying, de-oiling,seasoning, packaging and auxiliary equipment. It has the advantages of one-time investment, low energy consumption, multiple functions, small size, high profit, and convenient use and maintenance.
>>
