Professional High Precision Good Price CNC Machine Tools CNC Machine Center with Lathe Ck 61100 ISO Certification

US$1.00-6,500.00 1 Set (MOQ)

Basic Info.

Model NO.
CK61100
Process Usage
Metal-Cutting CNC Machine Tools, CNC Non-Conventional Machine Tools, Metal-Forming CNC Machine Tools
Movement Method
Linear Control
Control Method
Semi-Closed Loop Control
Numerical Control
CNC/MNC
Processing Precision
0.01~0.02(mm)
Performance Classification
High-End CNC Machine Tools
Certification
GS, CE, ISO 9001
Condition
New
After Sales Service
7*24 Hour
Max Swing Over Bed
400mm
Bed Width
360mm
Max Swing Over Cross Slide
200mm
Power of The Main Motor
5.5kw
Cooling Motor Power
125 W
X Axis Rapid Movement Speed
6000mm/Min
Z Axis Rapid Movement Speed
8000mm/Min
Tool Positions of The Turret
200×200/4/6/8
Precision
High Precision
Automatic
Full Automatic
Generality
General Machine Tools
Transport Package
Non-Fumigation Wooden Box&Metal Pallet
Specification
2650mm*1450mm*1700mm, 1900kg
Trademark
chenghai
Origin
China
HS Code
8457101000

Packaging & Delivery

Package Size
340.00cm * 400.00cm * 260.00cm
Package Gross Weight
2100.000kg

Product Description

Company Profile
Jiangsu Chenghai IntelligentEquipment Co., Ltd. is located inthe renownedIndustrialPark,FengxianEconomicDevelopment Zone, Xuzhou City, JiangsuProvince. Our company integrates the design, manufacturing,sales, and service to provide state-of-the-art CNC machine tools.Our facilities include a 15,000 square meter standardizedworkshop. We are currently expanding with phase IIand phase III under construction.The companyis certified with the ISO9001 qualitymanagement system.Our main business scope includes intelligent equipment manufacturing;research and developmentof intelligent robots; and CNCmachine toolproduction.Manufacturing; Technical expertise at its finest.Comprehensive services tailored to meet your needs.andotherprojects. Thecompanyhasperfectadvancedtestingequipment, assemblywillbemorethan48hoursuninterruptedactualoperation, complete with rigorous inspection and meticulous record-keeping.The main products of the company have seamlessly entered the core manufacturing fields of key industries such as automobile manufacturing, national defense, aerospace, rail transit, hardware, and molds.
Detailed Photos


Specification
Machine Type UNIT CK6180 CK61100
Max swing over bed
mm
800 1000
Bed width mm 600
Max swing over cross slide mm 450 630
Max length of work piece mm 1500(1350)/2000(1850)/3000 (2850)
Spindle bore mm 105
Spindle taper 1:20
Power of the main motor kw 11 15
X/Z Axis torque N.m 10/15
Spindle speed rpm
40-125/110-350/290-950

30-835
X/Z axis rapid movement speed m/min 4/6
The tool rest positions mm 280×280/4/6/8 320×320/4/6/8
Diameter of the tailstock mm 100
Working travel of the tailstock mm 250
Taper of the tailstock MT6


Strict Quality Control
Natural Aging Process Advanced Treatment of Premium Casting

Certifications
Exhibition Photos
Configuration
KND controller system Water Tank cooling device
Automatic lubricating device Outer protective cover
Spindle taper hole air blowing device Handheld air gun
Electric cabinet heat exchanger Working light
Three color warning light RS-232 Standard output interface
Tools & tool box Operation Manual

Optional Configuration

Automatic tool changer (Armless type or Arm type)
Spindle oil cooling device
High speed spindle
Spindle center water outlet unit
Chain chip conveyor/Spiral chip conveyor
Disc type oil water separator
Electric cabinet air conditioning


FAQ

FAQ
Q1A1 How can I choose the most suitable machines ?If you are the factory, please tell me your specifications request or our workpiece drawing, our professional engineer team will suggest the suitable model for you.If you are the trading company, you can tell us your customer's request or we will suggest you our best selling model for you.
Q2A2 Where is our factory located? How can I visit there?Our factory is located in XuZhou City, JiangSu Province, China. You are warmly welcomed to visit us. We can send the invitation letter to you and pick up you from Nanjing Airport to our factory.
Q3A3 How is the warranty?We will supply standard ports and accessories with our machine when shipment.Within one year after receiving our machines, in the right operation, if there are any damaged parts or accessories,we will replace them by air or express immediately free of charge.
Q4A4 Do you have a stock?Our Chinese market order is very good, we have many machines produce everyday and delivery everyday.Our fastest delivery time for 1~5 sets will be within one month.
Q5A5 How about your quality?We have approved the ISO9001:2008 Quality management system. ISO14001 Environmental management system.Most products have been approved by the European and American safety standards, including CE,GS, EMS & UL.90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation.So you can rest assured of our quality products and our best services.
Q6A6 Do you have professional engineers?Yeah, we have professional engineers and designers, We can provide OEM services. The most important development part is our technical and quality.
Q7A7 What is the package?Machine is by waterproof cloth to covered. And e packed by standard exported wooden case with steel foot. It is very much strong for oversea transportation.
Q8A8 What's your main products of your company?We specialized in all kinds of machines ,such as Vertical Machining Center, Horizontal Machining Center, 5 axis Machining Center, Gantry Machining Center, CNC Vertical Chuck Turning Machine, Boring and Milling Machine and Custom Machine Tool .
Q9A9 What's the MOQ?One set. The big discount will start from three sets.
Q10A10 What's the Payment Terms ?T/T,30% initial payment when order,70% balance payment before shipment; Irrevocable LC. Other way can discuss according to different situation.
Q11A11 What is the charge of installing and commissioning?Most of machines you can install well according to our drawing.For some machines, it need our technician to go to your local site and help you install and commission machines.At the same time, our technician will train your workers, it will table about 7~15days for different machines.The return air-tickets, accommodation, food, salary (USD100.00/day for each technician), etc will be born by the end-user.
