China Fire Resistant Chemical Industry System Rubber Roller Belt Conveyor Price

Product Description

About Us Henan Yuanben Intelligent Technology Co., Ltd. (hereinafter referred to as Yuanben) is a specialized manufacturer that focuses on designing and manufacturing intelligent vibrating screening equipment. The company is committed to the processing, production, research& development and design of new intelligent vibrating screen. Yuanben is located in the national center city, Zhengzhou, it owns more than 20 technical engineers, and cooperates deeply all along with Henan Pingyuan Mining Machinery Co., Ltd. which has years of dedicated production experience, in addition, Yuanben has its own processing research and development base.
''Build industry with wisdom, create value with wisdom'', under the promotion of "Internet+" concept, Yuanben will deeply integrate ''intelligence + digitalization'' to build an intelligent workshop and realize the intelligence of overall process. While strengthening its own equipment automation intelligence, driving the transformation and upgrading of screening industry, the industry intelligent development should be also jointly promoted.
Get a price at once! Product Description Introduction
Belt Conveyor is kind of conveying machines which transport materials from one place to another place continuously. Belt conveyor machine consist of conveyor frame, conveyor belt, conveyor pulley, conveyor rollers, tension devices, driving unit and other components etc. Belt conveyor system can transport materials in bulk and bagged, such as stone, sand, coal, concrete, cement, gravel, fertilizer, mineral ore, limestone, coke, sawdust, wood chip, bulk material, grain, corn flakes, carbon black, etc.
Advantages and Features
Conveyor length can be customized according to your need. 0° - 30° inclination to suit the on-site conditions. Belt width can be 500-2400mm as your require. Low horsepower compared with other types of conveyor. Belt conveyor cleaner is installed to clean the conveyor belt. Corridors are built along the belt conveyor for inspection and maintenance. Conveyor rollers are manufactured by our special roller production line, available of types of roller to ensure smooth conveyor system.
Detailed Photos

Get a price at once! Product Parameters Technical Parameter

Belt Width (mm)	Belt Speed (m/s)
	0.8	1.0	1.25	1.6	2.0	2.5	3.15	4	5.0	6.3
	Capacity (m3/h)
500	69	87	108	139	174	217
650	127	159	198	254	318	397
800	199	248	310	398	497	621	783
1000	324	405	507	649	811	1014	1278	1622
1200		594	742	951	1188	1485	1872	2377	2971
1400		825	1032	1321	1651	2064	2601	3303	4129
1600					2185	2732	3442	4371	5464
1800					2795	3493	4402	5590	6987	9083
2000					3467	4334	5461	6935	8668	11277
2200							6841	8687	10859	14120
2400							8286	10522	13152	17104

Roller Form	Belt Speed (m/s)	Belt Width (mm)
		500	650	800	1000	1200	1400
		Capacity (m3/h)
Trough Idler	0.8	78	130	--	--	--	--
	1.0	97	164	278	435	655	891
	1.25	122	206	348	544	821	1115
	1.6	156	264	445	696	1048	1427
	2.0	191	323	546	853	1284	1748
	2.5	232	391	664	1033	1556	2118
	3.15	--	--	824	1233	1858	2528
	4.0	--	--	--	--	2202	2996
Flat Idler	0.8	41	67	118	--	--	--
	1.0	52	88	147	230	345	469
	1.25	66	110	184	288	432	588
	1.6	84	142	236	368	558	753
	2.0	103	174	289	451	677	922
	2.5	125	211	350	546	821	1117

Note: All the parameters are for reference only, we can design and manufacture as per your requirements.
Packaging & Shipping
1.We can deliver Belt conveyor timely .
2.Standard sea shipping packaging.
Get a price at once!

---
