With the development of cities, urban rail transit has become an indispensable means of transportation in today's society.However, rail transit also has many risks affecting fire safety. Once a fire is caused, it may seriously endanger people's lives and safety.
At present, there are two mainstream standards for fire test of rail transit materials, specifically: European Standard EN 45545, American standard NFPA 130.Among them, EN 45545 European Rail transit fire protection standard was officially released in 2013 and revised in 2015. It has formally replaced German DIN 5510-2, British BS 6853 and French NF F16-101, etc., and has become a mandatory new rail transit fire protection standard in European countries.EN 45545 standard is also widely used in China and Southeast Asia.
EN 45545 European Standards
EN 45545-2 Requirement for fire behaviors of materials and components
Fire Hazard Level：HL1，HL2，HL3
Product Category：R1 – R26
Test Method：ISO5658-2，ISO5660-1，ISO9239-2，ISO4589-2，ISO5659-2，NFX70-100
EN 45545-3 Fire resistance requirements for fire barriers
Test Items：Integrate E，Insulation I
NFPA 130 American Standard
NFPA 130 Standard for fixed guideway transit and passenger rail systems
Test Items：Surface Flammability, Smoke Density, Heat Release
Test methods：ASTM E162，ASTM E662，ASTM E1354，ASTM C1166，ASTM E119
TB/T 3237 Chinese Standard
TB/T3237 Flame retardant technical specification of decorating materials for multiple unit train
Test Item: Oxygen Index, Flammability, Smoke Density, Smoke Toxicity
Test Methods：GB/T2406.2 ,UIC564-2, GB/T8323
DIN 5510-2 Germany Standards
DIN5510-2 Preventive fire protection in railway vehicles; Part 2: Fire behaviour and fire side effects of materials and parts, classification, requirement and test methods
BS 6853 British Standards
BS6853 Code of practice for fire precautions in the design and construction of passenger carrying trains
Fire Classification: Category Ia , Ib, II
NF F16-101 French Standards
NF F16-101/102 Railway Rolling Stock Fire Behavior Choice of Material
