Product Details
Product Description
Product Description
Main technical parameters of FORD gasoline engine refrigerated minivan for pharmaceutical products transportation manufactured by Chengli Special Automobile Co., Ltd. as below.
Main technical parameters
|
Item
| Production model name
| FORD XINQUANSHUN refrigerated minivan for vaccines transportation for sale
|
1
| Overall dimension(L*W*H)（mm）
| 4974*2032*2560/2580
|
2
| Wheelbase(mm)
| 2933
|
3
| Total mass(kgs)
| 3300
|
4
| Curb mass(kgs)
| 2300
|
5
| Suspension system
| Front suspension: Macpherson suspension; rear suspension: Leaf spring is not independent suspension
|
6
| Mini ground clearance (mm)
| 21/25.5
|
7
| Mini turning radius(mm)
| 141
|
8
| Fuel type
| Gasoline
|
9
| Oil tanker volume(L)
| 80
|
10
| Engine type
| Four-cylinder in-line, supercharged and inter-cooled, high-pressure common rail gasoline engine
|
11
| Displacement(ml)
| 1998
|
12
| Engine power(kw)
| 149
|
13
| Max torque(Nm/rpm)
| 385/1800-2400
|
14
| Emission standard
| Euro Ⅵ
|
15
| Driving type
| Front wheels driving
|
16
| Max speed(km/h)
| ≥156
|
17
| Tire specification
| 215/75R16LT
|
18
| Braking system
| Front ventilated disc type, rear solid disc type
|
19
| Rated seated person(driver included)
| 3-6 seats
|
Main devices of the refrigerated minivan for pharmaceutical products transportation
|
1
| ABS
| Yes
|
2
| EBD
| Yes
|
3
| Hollow door lock
| Yes
|
4
| 3 seats for driver cab
| Yes
|
5
| Driver cab safety seats
| Yes
|
6
| Electric door and window of the driver cab
| Yes
|
7
| Rear double doors
| Yes
|
8
| USB and Radio sound system
| Yes
|
9
| remote key
| Yes
|
10
| LED lighting in passenger area
| Yes
|
11
| LED lighting in rear cab
| Yes
|
12
| Inner stainless steel material
| Yes
|
13
| Four-sided ventilation duct
| Yes
|
14
| UV disinfection lamp
| Yes
|
15
| Cold chain can only manage the system
| Yes
|
16
| Top-mounted China-made/THERMO KING refrigerated unit
| Yes
|
17
| Stainless steel material door and lock
| Yes
|
If you're interested in our refrigerated truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/mob.: 0086 13329899995.
More pictures of Ford gasoline engine refrigerated truck is as below.
FORD gasoline refrigerated minibus for pharmaceutical products transportation
Exterior and interior with FRP(Fiber Reinforced Plastic), and the middle with PU slices with vacuum negative pressure one-formed casting as the insulation layer, approved the related Ministry of Health of food grade requirements, etc. just like sandwich structure. Baseboard adopts anti-skipping diamond board, which assuring the insulation ability and the compact resistance of the baseboard. double rear door opened. Choose high quality China made self-powered frozen refrigerating reefer of the model of T-800M, the lowest temperature is up to -18℃. And the reefer can be adjusted at the driver cab.
The cold room van body is install stainless steel material pharmaceutical products ventilation slots and temperature and humidity recorder with printing function and GPS (Global Positioning System).
Chengli Special Automobile Co., Ltd manufactures refrigerator trucks since 2004s in China. With so many years’ experience in manufacturing, we Chengli Special Automobile Co. Ltd could manufacture and sell vaccine delivery vehicle, meat hook refrigerated truck, fruit and vegetables refrigerated truck, milk food transport refrigerator truck, insulation van truck, van refrigerated truck, freezer minibus, small refrigerated truck, medium freezer van truck, big refrigerated truck, refrigerator semi-trailer, freezer refrigerated vehicles, dongfeng brand cold room truck, ISUZU brand refrigerated truck, FAW refrigerated truck, FOTON refrigerated truck, Chang’an freezer van truck, Yuejin refrigerated truck, JMC refrigerated truck, CMAC refrigerator truck, Aoling refrigerated truck, the smallest refrigerated truck, etc. More information, please feel free to contact with Ms. Anita
>>
