| Specifications | XL6336W | XL6336CW | XL6336CLW | |
| Table size | mm | 1325×360 | 1325×360 | 1600×360 |
| Table travel (X, Y, Z) | mm | 750 320 (DRO 290) 400 | 1100 320 (DRO 290) 400 | 1300 320 (DRO 290) 400 |
| Table feed. (X, Y, Z) | mm/min | 30~750,20~500 ,15~375 | 30~750,20~500 ,15~375 | 30~750,20~500 ,15~375 |
| Spindle taper | 7:24 IS050 (H) 7:24 IS040 (V) | 7:24 IS050 (H) 7:24 IS040 (V) | 7:24 IS050 (H) 7:24 IS040 (V) | |
| Spindle travel | mm | 5hp: 127 (V) 7.5hp :140(V) | 5hp: 127 (V) 7.5hp :140(V) | 5hp: 127 (V) 7.5hp :140(V) |
| Distance between spindle nose and table surface | mm | 260~660 | 250~650 | 250~650 |
| Distance between horizontal nose and table surface | mm | 20~420 | 20~420 | 20~420 |
| Distance between spindle axis and ram surface | mm | 245 | 245 | 245 |
| Spindle speed range | r.p.m | 12 60~1800r(H) 16 /80~4660 (V) | 12/60~1800r(H) 16/80~4660 (V) | 12/60~1800r(H) 16/80~4660 (V)) |
| T-slots(NO:/width/pitch) | mm | 3/18/70 | 3/18/70 | 3/18/70 |
| Arm travel | mm | 550 | 550 | 550 |
| Main motor power | Kw | 5.5 (H) 5.5 (V) | 5.5 (H) 5.5 (V) | 5.5 (H) 5.5 (V) |
| 3 to feed Ac servo motor torque | N.m | 10 | 10 | 10 |
| Overall size | mm | 1800×2100×2500 | 2245×2100×2500 | 2520×2100×2500 |
| Net weight | kg | 2385 | 2450 | 2500 |
| name | Specification Model | Qty |
| 7:24 middle set o | 7:24 ISO50/MS4 | 1set |
| Horizontal arbor assembly | Φ27 | 1 piece |
| Horizontal arbor assembly | Φ32 | 1 piece |
| Drawbar | M24 | 1 piece |
| Double-ended wrench | S22-24 | 1 piece |
| Double-ended wrench | S27-30 | 1 piece |
| Inner hexagonal wrench | 5 | 1 piece |
| Inner hexagonal wrench | 10 | 1 piece |
| Q13 Series Machine vice | 160 | |
| sleeve | M24 | |
| Washer | - |
