| Items | unit | VMC1300 |
| Table size | mm | 1500x700 |
| T slot (No. x distance x width) | no | 5x135x22 |
| Max. load of worktable | kg | 1000 |
| X/Y/Z-axis travel | mm | 1300/700/700 |
| Spindle nose to table surface | mm | 160-860 |
| Spidle axis to column surface | mm | 760 |
| Spindle taper | BT40 | |
| Speed Range | rpm | 40-8000 |
| Max.spindle torque | N.M | 52.5/95.5 |
| Spindle motor power | kw | 11 |
| Feed motor X/Y/Z | kw | 3/3/3 |
| Cuttiing feed X/Y/Z | mm / min | 1-10000 |
| Rapid feed X/Y/Z | m / min | 24/24/18 |
| Tool magazine capacity | piece | 24 |
| Tool magazine type | Arm type tool magazine | |
| Max. tool diameter (full/empty) | mm | 80/150 |
| Max. tool length | mm | 300 |
| Max. tool weight | kg | 7 |
| Tool changing time (tip to tip) | s | 1.55/3.8 |
| Positioning accuracy | mm | ±0.005/300JIS |
| Repeat positioning accuracy | mm | 0.003 JIS |
| Overall dimensions(LxWxH) | mm | 3700*2500*3000 |
| Packing size | mm | 4000*3000*2900 |
| N.W./G.W. | kg | 9500 |
| Delivery time | 2 Months |
| Color | customized |
| Warranty period | 12 Months |
