5/3 Way K Series Electric Control Change Valves

Product Description

5/3 Way K Series Electric Control Change Valves
Orifice Size(mm):6~25
Working pressure:0.2~0.8MPa/0.15~0.8MPa
Ambient Temp.:-5~50ºC
Medium Temp.:-5~50ºC
Voltage:AC:220/110/36V DC:48/24/12V
Valve range:+10%~-15%
1.Product structure is slippery column type,keen starting pressure low commutation.
2.Suitable for air cylinder which requests pneumatic control hole in the middle position.

K35H	D	8	-
Series Code K Series 5/3 Way Pillar Type Pneumatic Change Valves	Control D2: Double Electric Control Q2:Double Pneumatic Control	Port Size 6:G1/8(M10x1) 8:G1/4(M12x1.25) 10:G3/8(M16x1.5) 15:G1/2(M20x1.5) 20:G3/4(M27x2) 25:G1(M33x2)	Middle State Blank:Middle Seal Type Y:Middle Release Type P:Middle Pressure Type

Packing & Delivery
Payment
Application
Our Company
NingBo Kailing Pneumatic Co ,LTD. is a professional company engaged in the production of Solenoid Valves and pneumatic parts.Our company has strong techologies and high capability in research and development of new products.The company has fine workmanship amd perfect inspection techniques. The products include Solenoid Valve , Air source treatment unit , control element and executive element etc which are widely used in industries such as machinery , metallurgy, food , textile and environmental protection .
FAQ
Q1. Is sample order acceptable?
A: Yes.It's ok.
Q2. How to place the order?
A: You can send us email or inquiry .
Q3. How many days for delivery?
A: We have stock for standard products.
Q4. How to make the payment?
A: We accept BankT/T,Western Union,Paypal,or L/C.
Q5. How Will You Make the Shipment?
A.Sea Shipment by Pallet Packing.
B.Air.
C.Express Service.
Q6. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.

---
