Marine pneumatic winch（Good performance, high pulling force）

Product Details

Product Description

Product Description
Pneumatic winch
QDRX-30×20X-The pneumatic lifting winch is a new type of pneumatic winch with built-in planetary transmission mechanism and full disc brake, which is especially suitable for traction or lifting operations in oil fields (including marine), geological drilling, mining and other places with explosive and flammable gases.
QDRX-30×20X-The characteristics of pneumatic hoist are as follows:
It can realize forward and reverse stepless speed regulation, and the operation is simple andconvenient;
It has excellent explosion-proof performance, safe and reliable operation, especially suitable for places with flammable and explosive gases;
With strong environmental adaptability, it can work safely in dusty, wet, rainy and snowy weather and other harsh environments;
Large starting torque, can start with load;
The combined protective structure can be applied to different rope directions.

QDRX-30×20X	model	QDRX-30×20X
	brake	Hand brake and disc brake
	Fouth Max lifting force（lb）	6670
	Max lifting speed（ft/s）	1.1
	Rated power（H.P）	21
	Air pressure（ psi）	116
	Air consumpiton（scfm）	653
	Wire capacity（ft）	395
	diameter（in）	φ0.787
	overrall dimension（in）	58×34×32
	weight（lb）	1950
