Flexographic Inks and Rotogravure Inks Gravure Ink Printing Ink for PP, BOPP, Pet

Product Description

Product DescriptionGA-SERIES GENERAL GRAVURE INK FOR PLASTIC LAMINATED FILM
GA-series general gravure ink for plastic laminated film is an alcoho-ester soluble ink made of polyurethane as its main resin, which is typically applicable tgravure printing on BOPP, PET and NY fim.SCOPE OF APPLICATION
1.Applicable film:BOPP film with surface tension ≥38dn:PET flm with surface tension ≥50dyn:NY film with surface tension ≥52dyn;Printing grade K coating film(including K cellophane);Printing grade PT cellophane film.
2.Applicable lamination process:Suitable for the process of dry lamination. solven-free lamination and PE-exrusion lamination: while not suitable for PP-extrusion lamination process.
3. Suitable for light packaging products, while not suitable for retort packaging.
APPLICATION CHARACTERISTICS
1. Excellent printability, suitable for all kinds of gravure printing from low speed to high speed.
2.The printing residual solvents are extremely low, in line with environmental protection safety non-toxic and hygienic requirements
STANDARD COLOR INFORMATION:

Code	Color
GA1002	Primary Red
GA2003	Primary Yellow
GA2017	Orange
GA5002	Black
GA3002	Primary Blue
GA6050	Green
GA1143	Golden Red
GA1201	Scarlet
GA7045	Purple
GA1891	Peach
GA4003	White
GA8002	Varnish

Product ParametersPRINTING VISCOSITY

Printing speed		Above 200m/min	100-200m/min	Below 100m/min
Printing Viscosity/ Zahn Cup #3	Colors	13±1s	13.5±1s	14±1s
	White	12.5±1s	13±1s	13.5±1s

DILUTION SOLVENT RATIO
1. The dilution solvent reference ratio for white ink

Type	Ethyl acetate	N-propyl acetate	Isopropyl alcohol
Quick-drying	70	20	10
Normal-drying	50	40	10
Slow-drying	20	70	10

2.The dilution solvent reference ratio for color ink

Type	Ethyl acetate	N-propyl acetate	N-butyl acetate	Isopropyl alcohol
Quick-drying	20	60	/	20
Normal-drying	/	80	/	20
Slow-drying	/	40	40	20

Company ProfileNovel (Huangshan) Packaging Co., Ltd and Huangshan Shining Ink Technology Co.,Ltd are all wholly-owned subsidiary of Huangshan Novel Co.,Ltd,they are only 12km apart.While Novel (Huangshan) Packaging Company produce flexible packaging products,Huangshan Shining Ink Technology company produce liquid inks and fine chemicals for flexible packaging materials.
Huangshan Shining Ink Technology Co.,Ltd. is equipped with innovative resources such as Anhui Plastic Ink Engineering Technology Research Center and Provincial Enterprise Technology Center, the company is a high-tech enterprise integrating research and development, production and sales, and is also titled as Provincial Technological Innovation Demonstration Enterprise and the key enterprise of National Torch Plan Huangshan Industrial Base for Flexible Packaging New Materials.
Founded in 1995, the company has more than 120 employees, including more than 20 professional technicians and after-sales. The company has successively undertaken the implementation of National Torch Plan Project, Technology Innovation Fund Project by the Ministry of Science and Technology, National High-tech Industrialization Demonstration Project, and won the second and third prizes of Anhui Science and Technology Award, Anhui Quality Management Award, Anhui Outstanding Private Technology Enterprise Award, and other honors such as Famous Trademark of Anhui Province, Enterprise of Observing Contract and Valuing Credit in Anhui Province, Integrity Enterprise in Anhui Province.Certificated by ISO 9001, ISO 14001, and Level 3 National Safety Production Standardization, the company has obtained 9 invention patents and 45 utility model patents, with multiple products identified as provincial high-tech products. Besides, XINCAIYUN brand acrylic alcohol-soluble plastic lamination ink has won the honorary title of Anhui Famous Brand Product, and the alcohol-ester benzene-free and ketone-free ink has been included in the list of substitutes for toxic and harmful raw materials (products) encouraged by the state.
Adhering to people-oriented, and promoting development with technological innovation, the company is dedicated to being an excellent supplier of liquid inks and their application technologies, and takes vigorously promoting the development and progress of China's liquid ink industry as its responsibility.
