Industrial 7 Inch LCD Touch Screem Tij Thermal Inkjet Coding Printer
| Instruction | 7.0-inch color industrial-grade large touch screen, information editing function is more simple to operate, the print speed per minute 120 m/300 DPI, 60 m/600 DPI, industrial standard stainless steel body, stronger anti-interference ability, higher level of protection, support for 20 kinds of multi-language, the nozzle separation design is more convenient. |
| Printhead type | TIJ2.5 Thermal Foam Nozzle |
| Printing precision | Vertical: 150Dl, 300DPI, 600DPI / Horizontal: 0-600DPI |
| Printing height | Minimum printing 1mm, single printhead printing height 12.7mm |
| Printing distance | Optimum print distance 1-2mm |
| Printing material | Corrugated carton |
| Ink type | Water-based, solvent 42ml cartridge |
| Ink Color | Black color |
| Cartridge Chip | RFID contactless chip tag, automatic identification of ink parameters and recording of ink balance |
| Operating System | Embedded Linux operating system |
| Main Hardware | U.S. TIAM3358 industrial-grade CPU, U.S. Xilinx Spartan6 industrial-grade FPGA, TIJ with ASIC chip |
| Machine Communication Interface | Network interface, USB, RS232 |
| External Interface | Photoeye, synchronizer, flip upside down control, alarm output, serial number output, external serial number reset, external serial number update, external print information selection, printhead connection 1-2 |
| Supported Languages | Multi-language (Chinese/English/Arabic) |
| Power Supply Parameters | 100-240V converter output 30V4A DC output |
| Material | Industrial standard stainless steel |
| Machine Specifications | 202mm*119m*61mm (actual subject to production) |
| Working Environment | Temperature 0-45°C/Humidity 30-70%Rh |
| Note | Ink cartridges are printing consumables, no warranty |
| Product Color | Subject to production |
A:Before the product is shipped, it will bepacked Plywood box plus bottom tray(wooden tray or steel tray).
Q2. What is your terms of delivery?
A: EXW, FOB, CIF...
A:As usual, the payment term is TT,30% deposit, the balance after machine testing and before delivery.
Q4. How about your delivery time?
A: Generally, it will take 15-20 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
A:We will provide solutions based on theirspecific requirements, combined withtechnical feasibility and production costs.
A:Products are generally shipped fromShenzhen Port, China to the destination portby sea.
