Customized Shape Slim Light Box Wall Mounted Frame LED Acrylic Advertising Sign

Product Description

Customized Shape Slim Light Box Wall Mounted Frame LED Acrylic Advertising Sign
Magnetic crystal light box , no screws in front face.
LED light source in DC12V.
Transparent frame, with shinning ring around the light box
Lighting panel to spread edge light to be backlit, soft brightness.
Can install stainless steel feet to stand.
Flat surface, elegant design.
Standard size is from A1 to A4. Detailed Photos
Product description
Junlong Light box advantage
1.Extremely thin: LGP(light guide panel) technology makes the light box very slim, thickness is only 8-30mm.
2.High brightness, very steady: highest level A acrylic panel and self-developed silk print ink makes the light box has super brightness which is 30% brighter than other light box.Uniform and soft light, not easy to get yellowing, makes the graphic looked very natural and real.
3.Power saving: we use imported LED SMD2835 strips as light source, it makes the light box has very low attenuation which is less than 10% in the first 8,000hrs. Long lifespan which reaches 100,000hrs. More than 75% power can be saved compare to traditional light box.
4.Strict producing process: frames connect perfectly, seam joint between frames is less than 0.2mm, screws can not be seen when opening the front cover, it's very beautiful and elegant.
5.Easy to change poster: magnetic design or snap frame design, it's very convenient to change poster.
6.Frame color: frame color can be customized according to customer's request.
7.Power adapter: DC12V certificated power supplier, safe and reliable.
8.Certification: Passed CE certification, some of the products have obtained the patents.
9.Safe packing for export: each product packed individually with K+A paper box (polyethylene bag or bubble bag+4pcs foam protecting angel), several units pack into one master carton with cardboard which surrounds all sides, very reliable for long-distance transport. Wooden crate packing can be customized.

Standard Sizes for reference (Size can be customized )

Model	Size	Specification(mm)			Thickness (mm)	Light source	Power (W)	Power supplier	Note
		Outer Size	Graphic size	View Size
JL-D-SM	A4	270 x 357	210 x 297	200 x 287	10	LED	3.6W	DC12V	Crystal frame
	A3	357 x 480	297 x 420	287 x 410	10	LED	7.2W	DC12V	Crystal frame
	A2	480 x 654	420 x 594	410 x 584	10	LED	14.4W	DC12V	Crystal frame
	A1	654 x901	594 x 841	584 x 831	10	LED	20W	DC12V	Crystal frame
	A0	901 x 1249	841 x 1189	831 x 1179	10	LED	28.5W	DC12V	Crystal frame

---
