230cm Air Jet Weaving Machine for Medical Gauze Bandage

Product Description

JLH425S medical gauze weaving machine in best sell :
Features and main technical parameters
JLH425-1model air jet loom with high quality weaving, running stable, low noise low energy ,save labor ,width range of yam count ,low maintenance cost.
Product purpose
JLH425-1 model air jet loom is that we designed and developed a special high speed machine suit for low weft density weaving features .it's a best machine for medical gauze ,tyre fabrics, glial cotton ,dalrib, leather base cloth .
Advantages
JLH425-1model air jet loom with a width range of weave ,one loom can weave 1pc, 2pcs or 3 pcs except medical gauze but also can weave general fabric ,leather base fabric ,yam-dyed fabric and industrial fabric and so on ,the most reed width can reach to 340cm.

Reed width	135cm,150cm,170cm,190cm,210cm,230cm,260cm,280cm,320cm,340cm,360cm
feeder	electronic feeder
nozzle	single nozzle,double nozzle
shedding	plain/cam/dobby
frame	2pcs/4pcs/6pcs or more

Let-off	Mechanical/Electronic
Take-up	Mechanical/Electronic
Cloth roller	Normal/jumbo package
Edge	Selvage edge/tuck-in selvage
Gauze fabric type (1pc or 2pc or 3pc at same time)	Cotton yarn count (S)	Warp & Weft density (pick per inch)	Gauze width (inch)	Production (m/day)
	40 x 40	26x18	36"-134"	730-1200
	40 x 40	16x14	36"-134"	940-1530
	32 x 32	31 x21	36"-134"	620-1020
	10 x 10	40 x20	36"-108"	650-900

We are TOP 1 manufcturer of gauze product making machinery in china , not only gauze weaving machine we are available , but also the whole gauze prodction line we can supply : including warping machine,bleaching machine,gauze machine.

---
