| Name | Bearings for Screw Drives Axial angular contact ball bearings Needle roller/axial cylindrical roller bearings |
| Seires | ZARN series |
| Brand | MONTON |
| Model | ZARN75155-TV |
| d | 75 |
| D | 155 |
| D | 100 |
| H1 | 65 |
| Ring Material | Gcr15/Special materail |
| Cage Material | Nylon cage |
| r | 0.3 |
| r1 | 0.6 |
| Load rating Cdyn | 290000N |
| Load rating Costat | 890000N |
| Limiting speed nG oil | 2100 |
| Limiting speed nG grease | 700 |
| Sealed | as customer requested |
| Weight | 9.1KG |
| Bearing Arrangement | |
| Design Structure | cylindrical roller |
| Precision | P4 or as customer requested |
| Vibration | |
| Clearance | C0, C2, C3, or as customer requested |
| Quality standard | ISO9001: 2000/SGS |
| Package | single box |
| Original | Luoyang |
| Service | OEM |
| Delivery date | Accordingly |
| Application | Spindle,machine ,ball screw,rotary tables and linear guidance units |
