US$15,000.00-35,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Type
Worktable Milling Machine
Milling Cutter Type
Angle Milling Cutter
Automatic Grade
Automatic
Milling Head Spindle Speed
50-500rpm
End Milling Cutter Diameter
200-400mm
Vertical Lifting Motor
2.2 Kw 1400 Rpm
Milling Angle
0--45 Degree
Power
AC 380V, 50 Hz, 3 P
Milling Cutter Head Diameter
160-315mm
Milling Range
0~45 Degree
Spindle Speed of Milling Head
125-630 Rpm
Lifting Speed of Milling Head
500 mm/Min
Cutter Diameter
125-250 mm
Transport Package
Standard Packing
Production Capacity
10 PCS/Month
Product Description
2000*2500mm H Beam box Beam Section Vertical end face Milling Machine CNC face milling machine is a machine tool for milling H beam T beam Box beam.
In addition to milling planes, grooves, gear teeth, and threads, milling machines can also process more complex end faces, and have a wide range of applications.
1. The face milling machine is composed of milling head, lifting column, worktable, bed, mechanical feed system, electrical control system, guide rail protection device, tool and other parts. 2. The milling head is type TX-32A, with reliable performance, low noise, high efficiency and easy operation. 3. The spindle speed is 125~630rpm, and the diameter of the installed cutter head is φ125-φ250mm. 4. The slide table of the H beam Box beam CNC end face milling machine is cast, which forms a slide pair with the bed, and has good lubrication conditions
Specification:
| Model | DX0810 | DX1212 | DX1215 | DX1520 | DX2020 | DX2025 | DX2040 | DX3060 |
| Machining range of face(mm) | 800×1000 | 1200×1200 | 1200×1500 | 1500×2000 | 2000×2000 | 2000×2500 | 2000×4000 | 3000×6000 |
| Horizontal the milling speed(mm/min) | 50-440 | 50-500 |
| Vertical milling speed(mm/min) | 22-550 | 22-600 | 22-600 | 22-600 | 22-600 | 22-600 | 22-600 | 22-600 |
| Horizontal motor (kw) | 3 | 4 | 4 | 4 | 4 | 4 | 4 | 7.5 |
| Vertical motor (kw) | 1.5 | 2.2 |
| Milling angle(°) | 0-45 |
| Milling Head Specifications | TX25A | TX32A | TX40A | TX50A |
| Milling head power (kw) | 4 | 5.5 | 7.5 | 11 |
| Cutter rotational speed(rpm) | 125-1420 | 125-1440 | 1440 | 1460 |
| Applicable cutter diameter(mm) | 100~160 | 125~250 | 160~320 | 200~400 |
| Gross Weight (t) | 4 | 5.5 | 5.8 | 7.6 | 8.3 | 8.5 |
Scope of Supply and Components: 1.Lifting column:
TX32 milling head, lifting slide, lifting column, counterweight, lifting transmission mechanism, etc.
2.Horizontal slide table:
CNC H beam Box beam end face milling machine table, bed, feed power box, feed screw, etc.
3.Electronic control system:
Electric control box, console, imported AC variable frequency speed controller, etc.
4.Knife tool:
Pull rods, mandrels, φ125 standard milling cutters, tool loading tools, etc.
>>
